9140 Series Triple Output Multi-Range DC Power Supply

B&K Precision’s new 9140 Series Triple Output Multi-Range DC Power Supply combine industry-leading power density and performance with an extensive feature set – all in a compact 2U form factor. Three isolated output channels each produce 100W of clean power with low ripple and noise characteristics. Combine channels for up to 300W total output power.

Multiple outputs, USB data logging, and comprehensive protection features make these power supplies for a wide range of benchtop or test system applications. Powerful list mode programming enables users to set up and execute complex test sequences directly from the front panel.

Model Number Description

Triple Output DC Power Supply 32V 8A Channels 300W Total


Triple Output DC Power Supply 60V 4A Channels 300W Total

Features and benefits:

  • Three independent, floating output channels for up to 100W per channel or 300W total
  • High power density, compact 2U half-rack form factor
  • Multi-ranging operation
  • Low output ripple and noise down to 1 mVrms
  • Combine outputs to increase voltage up to 180V or 24A (depending on model)
  • Advanced and easy to use list mode programming
  • Channel coupling, tracking, configurable delays
  • Direct data logging to USB flash drive
  • Thermostatically controlled fans for quiet operation
  • Adjustable voltage and current slew rates
  • OVP, OCP, OTP, and key-lock protections
  • USB (USBTMC-compliant) and LXI compliant LAN standard, GPIB option
  • LabVIEW TM, IVI-C, and IVI.NET drivers provided
  • Operating software included
  • cTUVus certification mark
