Handheld Best in Class Versatile Multi-Function Recorders

The DAS 30/50/60 high speed multi-function recorders feature versatile channel  configurability, high speed sampling (1 MSa/s), a wide input range (±5 mv to ±500 V), large  internal solid state memory (up to 64 GB), and 9.5 hours of battery life. Combined with the  CAT III isolation rating, these instruments are well suited for applications ranging from small sensor signal logging to electrical power analysis.

The best-in-class 2 µs sampling interval in file mode lets you capture transient events with  confidence. Additionally, the large built-in  memory allows for data recording over longer periods of time.

Each channel can record a different signal such as voltage, temperature, current or frequency simultaneously, using a common time base. The next-generation touchscreen features unlimited data scrolling, zoom in/out function as well as drag and drop delta cursors for precision measurements.


Features & Benefits

  • Fast 1 MSa/s sample rate (memory mode) and 100 kHz bandwidth for capturing intermittent events
  • Accurately view and record signals from ±5 mV to ±500 VDC and 424 VRMS
  • CAT III 600 V rated isolated channels
  • Wide 10-inch touchscreen TFT display
  • Capture mixed signals with one instrument, such as high voltage/current waveforms, temperature and logic
  • Battery life up to 9.5 hours
  • 64 GB (DAS60) and 32 GB (DAS30/50) built-in solid state memory
  • 2, 4, or 6 universal analog channels
  • 14-bit resolution
  • 16 logic input channels
  • Temperature measurements supporting thermocouples and Pt100/Pt1000 sensors
  • Frequency counter
  • 2 USB host ports and one LAN interface
  • Free software for control and analysis
  • Virtual Networking Computing (VNC)
  • 110 mm integrated thermal printer (optional)

Applications

  • Measure signals ranging from small sensors to large electrical systems
  • Maintenace and failure analysis
  • Power analysis of single and three phase systems
All Models in the DAS 30/50/60 Series:
Model Number of Channels Factory Options
DAS30 2 -
DAS30-T 2 Pt100/Pt1000
DAS50 4 -
DAS30-P 2 Thermal Printer
DAS50-T 4 Pt100/Pt1000
DAS30-PT 2 Thermal Printer, Pt100/Pt1000
DAS50-P 4 Thermal Printer
DAS50-PT 4 Thermal Printer, Pt100/Pt1000
DAS60 6 Pt100/Pt1000
DAS60-P 6 Thermal Printer
