Keysight InfiniiVision Application Specific Software

Application Specific Software Products for Keysight InfiniiVision Oscilloscopes

Six optional application-focused and one ultimate bundle software package are supported on InfiniiVision oscilloscopes. The application-focused packages are targeted at Automotive, Aerospace & Defense, Embedded Design, Power Testing, USB 2.0, and NFC measurement applications. Unlike other oscilloscope software options in the market, you don't need to worry about which individual protocols and/or advanced analysis features you need to select and purchase for your scope. Each of the InfiniiVision software packages come with a suite of serial protocols and advanced measurement capabilities tuned for a broad set of industry/application-specific measurement applications.

For example, there are multiple automotive protocols and features required for testing today's automotive serial buses. With InfiniiVision's automotive software package you can get all automotive-related trigger, decode and analysis features you need, including CAN, CAN FD, LIN, CXPI, FlexRay, SENT, PSI5 (user-definable Manchester), user-definable NRZ, mask limit testing, and frequency response analysis (Bode plot). Moreover, the price you'll pay for a suite of measurement capabilities and protocols in a single software package from Keysight may be less than the price of other vendor's single protocol option.

Download the InfiniiVision Software Ordering Guide

Ultimate Software Packages - BEST VALUE!
The Ultimate Bundle Software Package bundles all the serial bus protocol trigger & decode capabilities, as well as all the advanced measurement capabilities of the individual licensed industry/application software packages (Auto, Power, Aero, USB, and Embedded). In addition, this package enables the NFC trigger and automated NFC test software.

InfiniiVision Series 2000A 3000A 3000T 4000A 6000A P9240
Ultimate Package Model D2000BDLA D3000BDLA D3000BDLA D4000BDLA D6000BDLA P9240BDLB

Automotive Software Packages
The Automotive Software Package for Keysight’s InfiniiVision oscilloscopes enables protocol triggering and decode for a broad range of the most common automotive serial buses used today for power train and body control and monitoring. This package also enables other advanced analysis capabilities including eye-diagram mask testing and frequency response analysis to help test and debug automotive electronic systems.

InfiniiVision Series 2000A 3000A 3000T 4000A 6000A P9240
Automotive Package Model D2000AUTA D3000AUTA D3000AUTA D4000AUTA D6000AUTA P9240AUTB

Embedded Software Packages
The Embedded Software Package for Keysight's InfiniiVision oscilloscopes enables protocol triggering and decode for a broad range of the most common serial buses used today for embedded and mixed-signal designs. This package also enables other advanced analysis capabilities including mask testing and frequency response analysis to help test today’s electronic designs.

InfiniiVision Series 2000A 3000A 3000T 4000A 6000A P9240
Embeded Package Model D2000GENA D3000GENA D3000GENA D4000GENA D6000GENA P9240GENB

Power Software Packages
The Power Software Package for Keysight's InfiniiVision oscilloscopes enables a broad range of automated power supply characterization measurements including critical frequency response measurements such as power supply rejection ratio (PSRR) and control loop response. This package also enables hardware-based pass/fail mask testing and USB PD triggering and decode.

InfiniiVision Series 3000A 3000T 4000A 6000A
NFC Package Model D3000PWRA D3000PWRA D4000PWRA D6000PWRA

NFC Software Packages
Keysight's low-cost near field communication (NFC) test solution consists of an InfiniiVision X-Series oscilloscope, Trueform waveform generator, programmable 3-in-1 NFC reference antenna (poller, listener, and resonant frequency coils), and PC-based NFC compliance test software that performs thorough analog testing of NFC-enable devices. All 4-channel InfiniiVision oscilloscopes in the table below (DSO or MSO models) are compatible with performing NFC compliance testing.

InfiniiVision Series: 3000A 3000T 4000A P9240
Aero Package Model D3000NFCA D3000NFCA D4000NFCA P9240NFCB

USB Software Packages
The USB Software Package for Keysight's InfiniiVision oscilloscopes enables USB 2.0 low-, full-, and hi-speed protocol triggering and decode, as well as USB PD (Power Delivery) trigger and decode. This package also enables other advanced analysis capabilities including USB 2.0 automated signal quality testing, jitter analysis, mask testing, and frequency response analysis (Bode plots) to help test and debug high-speed digital signals, such as USB 2.0.

InfiniiVision Series 4000A 6000A
USB Package Model D4000USBA D6000USBA
