Keysight InfiniiVision 1000 X-Series Oscilloscopes
Get measurements you can count on!

Get measurements you can count on to create the designs that will change the future. The 1000 X-Series leverages the same, proven technology we use in our higher-end InfiniiVision family, giving you professional-level measurements you can trust.

Now you can get even more functionality with capabilities like serial decode and remote connection via LAN, even on 2-channel models. Get the performance you need to measure with confidence.

Professional-level capabilities in an entry-level instrument:

  • Models from 50 MHz to 200 MHz of bandwidth
  • 2 or 4 channel versions
  • Standard LAN connectivity
  • Standard serial bus analysis
  • Standard mask testing (DSOX models)
  • Standard segmented memory (DSOX models)
  • 6-in-1 Instrument Integration:
    • Scope
    • DVM
    • Counter
    • Serial protocol analyzer
    • Function generator (G models)
    • Frequency response analyzer, Bode plots (G models)

NEW – Enhancements to 4-Channel DSOX1204A/G

  • Increased memory (1 Mpts to 2 Mpts)
  • Increased number of segments (50 to 500)
  • Decreased segmented re-arm time (19 µs to 1 µs)
  • New serial lister display
  • Serial decode now included (I2C, SPI, UART/RS232, CAN, LIN)
  • DVM and Counter no longer requires registration to enable

NEW – 2-Channel models with increased update rate, memory, standard serial protocol analysis, and more.

Limited Time Offer Get a free DSOxBODE with purchase of EDUX1052G, DSOX1202G, and DSOX1204G! Offer ends May 31, 2021.

  NEW
EDUX1052A
NEW
EDUX1052G
NEW
DSOX1202A
NEW
DSOX1202G
IMPROVED
DSOX1204A
IMPROVED
DSOX1204G
Bandwidth
(with upgrade
)
50 MHz 70 MHz
(100 MHz, 200 MHz)
70 MHz
(100 MHz, 200 MHz)
Channels 2 channel + external digital channel 4 channel
Max Sample rate 1 GSa/s 2 GSa/s
Memory 200 kpt 2 Mpts
Update rate 100,000 wfms/s 200,000 wfms/s
Display 7 inch WVGA
Connectivity LAN, USB host, USB device
Built-in WaveGen No Included No Included No Included
FRA (Bode Plots) No Included No Included No Included
Serial I2C, RS232/UART I2C, SPI, RS232/UART, CAN, LIN
Mask Testing No Included (200,000 tests/sec)
Segmented Mem No Included
Warranty 3-year included, 5-year upgradable

Downloads:
InfiniiVision 1000 X-Series Product Fact Sheet
InfiniiVision 1000 X-Series Data Sheet
