NEW Keysight CXG Series Low-Cost RF Vector Signal Generators

IoT design and verification (DVT) engineers need to keep up with today’s expanding consumer electronic market. This is same for many general-purpose radio device designers.

Engineers like yourself need an economic and versatile test and measurement system that can handle the diverse consumer electronic devices and give the performance required to make receiver tests across several different wireless standards.

Keysight N5166B CXG X-Series RF vector signal generator is a low-cost, multi-functional signal source. With a waveform playback memory of up to 512 Msa the CXG can provide a few seconds and as much hours of a continuous signal without repeating, depending on sample rate.

The CXG helps characterize IoT and general-purpose devices by performing basic parametric testing of components and functional verification of receivers with great EVM to verify your component in a wireless communication system operates as expected. This signal generator enables you to cover your consumer wireless application testing needs including Bluetooth 5, V2X, Wi-Fi, NFC, NB-IoT, LoRa, ZigBee, and various other waveforms for playback.

  • Frequency range of 9 kHz to 3 GHz or 6 GHz
  • Optional internal baseband generator to 120 MHz/512 MSa or external IQ input
  • Optional AM, FM, phase, pulse, multifunction generators
  • Perform basic parametric testing of components and functional verification of receivers
  • Test your device with multiple verified, standards-compliant vector signals
  • Easily troubleshoot your component within a wireless communication system using a reliable vector signal generator
  • Cover your consumer wireless application testing needs including Bluetooth, Wi-Fi, NFC, NB-IoT, and other various waveforms for playback
  • Fully coded and framed signal for a short amount of time; good for packet PER or FER testing
  • Minimize downtime and expenses with self-maintenance solutions and low-cost repairs.

Models

N5166B 503 9 kHz to 3 GHz
N5166B 506 9 kHz to 6 GHz



Simplify Signal Creation with Pathwave Signal Generation Software (Signal Studio)

Signal Studio is signal creation software that runs on a PC.  It enables the creation of application specific test signals at baseband, RF and microwave frequencies.  Whether you need test stimuli in R&D or manufacturing, Signal Studio simplifies creation of the signals you need for characterization, verification and pass/fail testing of components, devices, receivers, and more.

Signal Studio comes with performance optimized signals, validated by Keysight.  You can easily modify these signals to meet your needs.  Or you may quickly create custom reference signals for testing devices.  Signal Studio capabilities are available to match just about any requirement and extend you signal creation to the widest variety of devices.

 Model Number Description
N7608EMBC Signal Studio Pro for Custom Modulation, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7610EMBC Signal Studio for IoT, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7624EMBC Signal Studio for LTE/LTE-Advanced/LTE-A Pro FDD, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7625EMBC Signal Studio for LTE/LTE-Advanced TDD, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7631EMBC Signal Studio Pro for 5G NR, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7606EMBC Signal Studio for Bluetooth, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7626EMBC Signal Studio for V2X, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7617EMBC Signal Studio for WLAN 802.11, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7607EMBC Signal Studio for DFS Radar Profiles, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7600EMBC Signal Studio for W-CDMA/HSPA+, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
N7602EMBC Signal Studio for GSM/EDGE/Evo, waveform playback;  Node-locked perpetual license with 12 months KeysightCare software support
