NGM 200 Series Single & Dual Power Supplies
High-Accuracy & Fast Load Recovery

The R&S®NGM200 Power Supply series is perfect for challenging applications requiring high accuracy and fast load recovery time. The two-quadrant architecture allows them to function both as a source and as a sink to simulate batteries and loads.  Their short recovery times enable them to handle fast load changes that occur, for example, when mobile communications devices switch from sleep mode to transmit mode.  They are all suited for all kind of applications where precise source and sink functionality is needed, especially whenever you need a wide range from a few μA to amps.

Ideal for use in labs and test systems
Tailored for use in labs and system racks. The NGM200 power supplies are the right choice for challenging applications. They are used in R&D labs and integrated into production test systems.
The power supplies can be installed in 19" racks using the HZN96 rack adapter. Connectors on the rear panel and a compact design are important criteria for use in test systems

Key Features:
  • Fast load regulation
  • Minimum residual ripple and low noise
  • Readings up to 6 and half digit resolution
  • Digital voltmeter functionality
  • Galvanically isolated floating channels
  • Output stage isolated with relays
  • Two quadrants: operates as a source and sink
  • Constant voltage, constant current and constant resistance models
  • Variable output impedence
  • High-speed acquisition (FastLog functionality)
  • Protection functions to safeguard instrument and DUT
  • Safety limits to safeguard the DUT
  • High-resolution touchscreen
  • Color coding of operating modes
  • QuickArb function
  • EasyRamp function
  • Save and recall instrument settings
  • Tailored for use in labs and system racks
  • Full remote capabilities
  • Sense function
  • Front and reara connectors
  • Fast on the bus and on the bench
  • Advanced instrument design: compact form factor, quiet operation
Key Facts
  NGM201 NGM202
Number of output channels 1 2
Total output power 60 W 120 W
Max. output power per channel 60 W 60 W
Output voltage per channel 0 V to 20 V 0 V to 20 V
Max. output current per channel < 6 V: 6 A, > 6 V: 3 A < 6 V: 6 A, > 6 V: 3 A
Load recovery time <30 µs <30 µs
Max. power and current per
channel when used as a load
60 W, 3 A 60 W, 3 A
Options
NGM-K102 Wireless LAN Remote Control 3644.6367.02 $475.00 $630.00
NGM-K103 Digital Trigger I/O 3643.9904.02 $365.00 $485.00
NGM-K104 DVM Option 3643.9927.02 $365.00 $485.00
NGM-B105 IEEE-488 (GPIB Interface) 3641.6220.02 $365.00 $485.00
NGM-K106 Battery Simulation 3636.6626.02 $975.00 $1,290.00
HZN96 19" Rack Adapter 3638.7813.02 $315.00 $420.00
