Powerful Trio of Signal Generators


When your testing requires the highest performance, the latest signal generators from Rohde & Schwarz deliver. Whether for 5G and GNSS (SMBV100B), robotics (SMB100B), aerospace (SMA100B), or other sophisticated application, features like greater signal purity, higher modulation bandwidth and more power, deliver the quality needed for the most demanding use cases.

All three models, in a range of configurations, are now in stock and ready for immediate shipment. In fact, TestEquity is North America’s only stocking distributor of the powerful, best-in-class 20 GHz SMA100B signal generator. There’s no need to wait months. Order today and take delivery tomorrow!

  • Frequency range from 8 kHz to 3 GHz, 6 GHz, 12.75 GHz, 20 GHz, 31.8 GHz, 40 GHz, 50 GHz and 67 GHz (overrange up to 72 GHz)
  • Excellent SSB phase noise of –152 dBc (typ.) at 1 GHz and –132 dBc (typ.) at 10 GHz, each at 10 kHz offset
  • Virtually no wideband noise (–162 dBc (meas.) at 10 GHz and 30 MHz offset)
  • Maximum output power exceeds 30 dBm across wide frequency ranges
  • Exceptionally low harmonics
  • Frequency range from 8 kHz to 1 GHz, 3 GHz or 6 GHz
  • Outstanding single sideband (SSB) phase noise of < –134 dBc (meas.) at 1 GHz and an offset of 20 kHz
  • Very low wideband noise of < –153 dBc (typ.) at 15 MHz < f ≤ 6 GHz and an offset of 30 MHz
  • Ultra high output power of 34 dBm (meas.) at 1 GHz
  • Compact form factor with 2 HU and ¾ 19" width
  • Large, state-of-the-art 5" GUI with touchscreen
  • Frequency range from 8 kHz to 3 GHz or 6 GHz
  • Ultra high output power up to +34 dBm
  • 500 MHz modulation bandwidth with perfect accuracy
  • Signal generation for all major digital communication standard incl. 5G NR, LTE and WLAN
  • GNSS simulator with GPS, Glonass, Galileo, BeiDou and QZSS/SBAS
  • Excellent EVM performance of 0.2%


The SMA100B RF and microwave signal generator delivers maximum performance without compromise. It provides purest output signals while maintaining the highest output power level, far outpacing the competition.
The new SMB100B RF signal generator is all about performance and versatility in a small footprint. Outstanding spectral purity and very high output power combined with comprehensive functionality and very simple operation are some of the impressive features of the SMB100B. It offers a frequency range from 8 kHz to 1 GHz, 3 GHz or 6 GHz.
The state-of-the-art SMBV100B vector signal generator sets new standards in its class. Ultra high output power, fully calibrated wideband signal generation and intuitive touchscreen operation make the SMBV100B ideal for all kinds of applications.
