Handheld Analyzers for Today’s Demanding Industries

Anritsu has a range of industry-leading handheld spectrum analyzers with measurement capabilities that cover frequencies from 9 kHz to 170 GHz. These compact, feature-loaded solutions provide flexibility in the field for locating, identifying, recording, and solving communication system problems without sacrificing measurement accuracy.






Spectrum Master Handheld Analyzer MS2720T – 9 kHz to 9/13/20/32/43 GHz

The MS2720T is one of Anritsu’s highest-performing handheld spectrum analyzers with new features and options that deliver even more value and speed.

  • Frequency ranges: 9 kHz to 9 GHz, 13 GHz, 20 GHz, 32 GHz and 43 GHz
  • Broadband preamplifiers for increased sensitivity approx. 17 dB
  • Three sweep modes: improved sweep speed, up to 100 times faster
  • Resolution and video bandwidths from 1 Hz to 10 MHz
  • New triggering choices including hysteresis, hold-off, and delay
  • More zero-span capabilities including 10 MHz RBW & VBW
  • Enhanced spectrum analyzer touchscreen GUI including large marker display choice
Learn More




Field Master Pro MS2090A – 9 kHz to 9/14/20/26.5/32/43.5/54 GHz

The Field Master Pro real-time spectrum analyzer delivers the highest levels of RF performance available in a rugged, handheld touchscreen spectrum analyzer. With continuous frequency coverage from 9 kHz to 54 GHz, the MS2090A is designed for technologies used in 5G networks (mmWave frequencies, active antenna systems, beamforming, and dynamic physical layer attributes) and supports today's wireless industries, including wireless service providers, broadcasting, regulatory authorities, aerospace/defense, satellite systems, and radar.

  • DANL: –164 dBm (with preamp)
  • TOI: +20 dBm (typical)
  • Analysis bandwidth: 100 MHz
  • Amp range: DANL to +30 dBm
  • Phase noise at 1 GHz: –110 dBc/Hz @ 100 kHz offset (typical)
  • Demodulation: 5GNR, LTE FDD, RF, and modulation quality plus SSB signal analysis
  • Resolution bandwidth (RBW): 1 Hz to 10 MHz
  • RTSA bandwidth: 22, 55, 110 MHz (option dependent)
Learn More
