TestEquity Tektronix Authorized Distributor

TestEquity - Your Authorized Tektronix Distributor

TestEquity is an Authorized Stocking Distributor for Tektronix Oscilloscopes, ARB/Function Generators, Digital Multimeters, Counters, DC Power Supplies, Probes, Accessories, and more. We are also a Tektronix Authorized Rental Company.

BASIC OSCILLOSCOPES
Series Bandwidth Record Length Options
TBS1000B 50 MHz - 200 MHz 2.5k Standard:
  • 2-channel - 6-digit freq. counters
  • 34 automated measurements
  • TrendPlot™
  • Advanced triggers
TDS2000C 200 MHz, 100 MHz,
70 MHz, 50 MHz
2.5 k
TPS2000B 200 MHz, 100 MHz 2.5 k
  • Battery Power (Standard)
  • Power Analysis
TDS3000C 500 MHz, 300 MHz, 100 MHz 10 k
  • Battery Power (Optional)
  • Limit Testing
  • Communications Mask Testing
  • HDTV/Custom Video
BENCH OSCILLOSCOPES
Series Bandwidth Channels Serial and Parallel Bus Analysis (optional)
MSO/DPO2000B 200 MHz, 100 MHz, 70 MHz 2 or 4 Analog
16 Digital (MSO Series)
  • I2C, SPI
  • CAN, LIN
  • RS-232/422/485/UART
  • Parallel (MSO Series)
MDO3000 Series 100 MHz - 1 GHz 2 or 4 Analog
16 Digital
+ RF Channel
Mixed Domain
  • I2C, SPI
  • CAN, LIN, FlexRay
  • RS-232/422/485/UART/USB2
  • I2S/LJ/RJ/TDM
  • Parallel Bus
  • MIL-STD-1553
MDO4000C Series 200 MHz - 1 GHz 4 Analog
16 Digital + opt. Spectrum Analyzer
  • I2C, SPI
  • USB
  • Ethernet
  • CAN, LIN, FlexRay
  • RS-232/422/485/UART
  • MIL-STD-1553
  • I2S/LJ/RJ/TDM
MSO/DPO5000B 350 MHz, 500 MHz,
1 GHz, 2 GHz
4 Analog
16 Digital (MSO Series)
  • I2C
  • SPI
  • RS-232/422/485/UART
  • USB
MSO5 Series 350 MHz, 500 MHz, 1 GHz, 2 GHz (Upgradeable) 4, 6, & 8 FlexChannels
  • I2C, SPI, RS-232/422/485/UART, CAN, LIN, FlexRay, USB 2.0, Ethernet, I 2 S, LJ, RJ, TDM
DIGITAL MULTIMETERS
Series Resolution Measurements Analysis Modes
DMM4020 5.5 Digit V ac, V dc, I ac,
I dc, Ω, Continuity, Diode, Frequency
  • Limit Compare
DMM4040 6.5 Digit V ac, V dc, I ac,
I dc, Ω, Continuity, Diode, Frequency, Period
  • Trendplot™
  • Statistics
  • Histogram
DMM4050 6.5 Digit V ac, V dc, I ac,
I dc, Ω, Continuity, Diode, Frequency, Period, Temper-ature, Capacitance
  • Trendplot™
  • Statistics
  • Histogram
Keithley DMM7510 3-1/2 to 7-1/2 Digit 100mV, 1Ω, 10μA
POWER SUPPLIES
Product Output Voltage Programmable
PWS2000 18 V – 72 V No
PWS4000 20 V – 72 V Yes
SPECTRUM ANALYZERS
Product Frequency Range Bandwidth Signal processing Starting Price
RSA306B 9 kHz to 6.2 GHz 40 MHz 10,000 spectrums per second $3,890
RSA500A 9 kHz to 3.0/7.5 GHz 40 MHz Real-time $6,020
RSA600A 9 kHz to 3.0/7.5 GHz 40 MHz Real-time $6,200
VECTOR SIGNAL GENERATORS
Series Frequency Range Freq. Resolution Phase Noise
TSG4100A 6.0 GHz, 4.0 GHz, 2.0 GHz 1 μHz -113dBc/Hz phase noise
ARBITRARY/FUNCTION GENERATORS
Series Bandwidth Channels Waveforms
AFG3000C 240 MHz, 100 MHz,
50 MHz, 25 MHz, 10 MHz
1 or 2
  • 12 standard including Sine, Square, Pulse, Ramp, Gaussian
  • Arbitrary waveform capability
  • Modulation and noise impairment options also available
AFG30000 250 MHz, 150 MHz, 100 MHz
50 MHz, 25 MHz
1 or 2
  • 12 standard including Sine, Square, Pulse, Ramp, Gaussian
  • Arbitrary waveform capability
  • Modulation and noise impairment options also available
AFG2021 20 MHz sine, 10 MHz square 1
  • Built-in, including: , Square, Pulse, Ramp, Noise, DC, Sin(x)/x, Gaussian, Lorentz, Exponential Rise, Exponential Decay, and Haversine
AFG1062 60 MHz sine, 30 MHz square waveforms 2
  • Continuous, sweeping, burst, and modulation modes (AM, FM, PM,ASK, FSK, PSK, PWM)
AFG1022 25 MHz 2
  • 50 built-in standard function and arbitrary waveforms
