Keysight 34980A Accessory Guide

Keysight 34980A Accessory Guide



34980A Modules and Accessories
Model Description Module Connectors Optional Terminal Blocks, Cables, Connector Kits
Mainframe - holds up to 8 plug-in modules
 34980A Multifunction switch/measure mainframe Comes standard with "DMM" option
Multiplexer Modules
 34921A 40-channel armature multiplexer w/low thermal offset
(order 34921T for temp reference)
2 - 50-pin Dsub, Male 34921T Terminal block with screw connectors

Y1135A - 1.5m 50-pin M/F Dsub cable
Y1136A - 3m 50-pin M/F Dsub cable
Y1139A - 50-pin female solder cup connector kit
 34922A 70-channel armature multiplexer 2 - 78-pin Dsub, Male 3492xT Terminal block, option 001 for solder connections, option 002 for screw connectors

Y1137A - 1.5m 78-pin M/F Dsub cable
Y1138A - 3m 78-pin M/F Dsub cable
Y1140A - 78-pin female solder cup connector kit
 34923A 40 / 80-channel reed multiplexer 2 - 50-pin Dsub, Male 34923T Terminal block with screw connectors

Y1135A - 1.5m 50-pin M/F Dsub cable
Y1136A - 3m 50-pin M/F Dsub cable
Y1139A - 50-pin female solder cup connector kit
 34924A 70-channel reed multiplexer 2 - 78-pin Dsub, Male 3492xT Terminal block, option 001 for solder connections, option 002 for screw connectors

Y1137A - 1.5m 78-pin M/F Dsub cable
Y1138A - 3m 78-pin M/F Dsub cable
Y1140A - 78-pin female solder cup connector kit
 34925A 40 / 80-channel optically isolated FET multiplexer 2 - 50-pin Dsub, Male 34925T Terminal block with screw connectors

Y1135A - 1.5m 50-pin M/F Dsub cable
Y1136A - 3m 50-pin M/F Dsub cable
Y1139A - 50-pin female solder cup connector kit
Matrix Modules
 34931A Dual 4x8 armature matrix 2 - 50-pin Dsub, Male 34931T Terminal block with screw connectors

Y1135A - 1.5m 50-pin M/F Dsub cable
Y1136A - 3m 50-pin M/F Dsub cable
Y1139A - 50-pin female solder cup connector kit
 34932A Dual 4x16 armature matrix 2 - 50-pin Dsub, Male 34932T Terminal block with screw connectors

Y1135A - 1.5m 50pin M/F Dsub cable
Y1136A - 3m 50-pin M/F Dsub cable
Y1139A - 50-pin female solder cup connector kit
 34933A Dual/quad 4x8 reed matrix 2 - 50-pin Dsub, Male 34933T Terminal block with screw connectors

Y1135A - 1.5m 50-pin M/F Dsub cable
Y1136A - 3m 50-pin M/F Dsub cable
Y1139A - 50-pin female solder cup connector kit
 34934A Quad 4x32 reed matrix 2 - 78-pin Dsub, Male 34934T Terminal block with screw connectors OR 34934C Configuration block

Y1134A - Row expansion cables for 34934C and 34934T
Y1137A - 1.5m 78-pin M/F Dsub cable
Y1138A - 3m 78-pin M/F Dsub cable
Y1140A - 78-pin female solder connector kit
General Purpose / Actuator Modules
 34937A 32-channel Form C/Form A general-purpose switch 2 - 50-pin Dsub, Male 34937T Terminal block with screw connectors

Y1135A - 1.5m 50-pin M/F Dsub cable
Y1136A - 3m 50-pin M/F Dsub cable
Y1139A - 50-pin female solder cup connector kit
 34938A 20-channel 5-amp Form A switch 2 - 50-pin Dsub, Male 34938T Terminal block with screw connectors

Y1135A - 1.5m 50-pin M/F Dsub cable
Y1136A - 3m 50-pin M/F Dsub cable
Y1139A - 50-pin female solder cup connector kit
 34939A 64-channel Form A Switch 2 - 78-pin Dsub, Male 34939T Terminal block with screw connectors

Y1137A - 1.5m 78-pin M/F Dsub cable
Y1138A - 3m 78-pin M/F Dsub cable
Y1140A - 78-pin female solder cup connector kit
RF and Microwave Modules
 34941A Quad 1x4 50-ohm 3-GHz RF multiplexer 20 - SMA  Requires standard 50 ohm SMA RF cables, adapters
8710-2576 SMA Extender for connecting SMA connectors
 34942A Quad 1x4 75-ohm 1.5 GHz RF multiplexer 20 - Mini SMB  Requires mini 75 ohm SMB RF cables, adapters
 34945A Microwave switch/attenuator driver  N/A  Requires 34945EXT and optional Y1150A-Y1155A distribution boards (one 34945EXT is automatically included in each 34945A order)
 34946A Dual 1x2 SPDT terminated microwave switch
Option 001: No switches installed
Option 004: 4 GHZ switches installed
Option 020: 20 GHz switches installed
Option 026: 26.5 GHz switches installed
6 SMA  Requires standard 50 ohm SMA cables and adapters
8710-2576 SMA Extender for connecting SMA connectors
Option 001 supports qty 2 of any of the following switches:
N1810UL unterminated SPDT
N1810TL terminated SPDT
N1811TL terminated 4-port transfer
N1812UL unterminated 5-port transfer
 34947A Triple 1x2 SPDT unterminated microwave switch
Option 001: No switches installed
Option 004: 4 GHZ switches installed
Option 020: 20 GHz switches installed
Option 026: 26.5 GHz switches installed
9 SMA Requires standard 50 ohm SMA cables and adapters
8710-2576 SMA Extender for connection to SMA connectors
Option 001 supports qty N1810UL unterminated SPDT switches
System Measurement & Control Modules
 34950A 64-bit digital I/O with memory and counter  2 - 78-pin Dsub, Female  34950T Terminal block with screw connectors

Y1137A - 1.5m 78-pin M/F Dsub cable
Y1138A - 3m 78-pin M/F Dsub cable
Y1142A - 78-pin male solder cup connector kit
 34951A 4-channel isolated D/A converter
with waveform memory
(DMM option required for calibration)
1 - 50-pin Dsub, Female 34951T Terminal block with screw connectors

Y1135A - 1.5m 50-pin M/F Dsub cable
Y1136A - 3m 50-pin M/F Dsub cable
Y1141A - 50-pin male solder cup connector kit
 34952A Multifunction module
with 32-bit DIO, 2-ch D/A
and totalizer
1 - 50-pin Dsub, Female 34952T Terminal block with screw connectors

Y1135A - 1.5m 50-pin M/F Dsub cable
Y1136A - 3m 5-pin M/F Dsub cable
Y1141A - 50-pin male solder cup connector kit
 34959A Breadboard module 26 & 40 pin internal ribbon cable connectors Any terminal block can be used assuming 50 or 78 pin Dsub is used



34980A Accessories
Accessories Description
 Y1130A Rackmount kit for 34980A, forward or reverse mount (order E3663AC rail kit for forward rack mounting or E3664AC rail kit for reverse rack mounting)
 Y1131A Verification and diagnostic tools for 34980A mainframe and modules
(select option for specific module support)
 Y1132A Module extender for 34980A. Extender cable to locate module outside of the mainframe.
Terminal blocks used for discrete wiring. Supports 20 AWG wire for <100 connections and 24 AWG for >100 connections
Multiplexer terminal blocks
34921T Terminal block for 34921A and L4421A Multiplexers
34922T Terminal block for 34922A Multiplexer
34923T Terminal block for 34923A Multiplexer
34924T Terminal block for 34924A Multiplexer
34925T Terminal block for 34925A Multiplexer
Matrix and GP terminal blocks
34931T Terminal block for 34931A Matrix
34932T Terminal block for 34932A Matrix
34933T Terminal block for 34933A and L4433A 4x8 Matrices
34934T Terminal block for the 34934A 512 Cross Point Matrix
Measurement and control terminal blocks
34950T Terminal block for 34950A and L4450A 64-bit digital I/O
34951T Terminal block for 34951A and L4451A D/A converters
34952T Terminal block for 34952A and L4452A Multifunction
Cables** used for direct cable connection to module, some modules require 2 cables
 Y1135A 1.5m 50-pin Dsub, M/F twisted pair with outer shield cable - 300V
 Y1136A 3m 50pin Dsub, M/F twisted pair with outer shield cable - 300V
 Y1137A 1.5m 78-pin Dsub, M/F twisted pair with outer shield cable - 300V
 Y1138A 3m 78-pin Dsub, M/F twisted pair with outer shield cable – 300V
Connector Kits** used to build custom cables
 Y1139A Solder cup connector kit for 34921/23/25/31/32/33/37/38 - 50-pin Dsub
female - 125V
 Y1140A Solder cup connector kit for 34922, 34924 - 78-pin Dsub female - 60V
 Y1141A Solder cup connector kit for 34951, 34952 - 50-pin Dsub male - 125V
 Y1142A Solder cup connector kit for the 34950A - 78-pin Dsub male - 60V
34945A Accessories - distribution boards required for control of external switches. One 34945EXT is required for each 64 coils (included, add more 34945EXTs  for additional coils)
 34945EXT External driver for 34945A, one required for each 64 coils - holds 4 distribution boards. Order Y1157A-Y1159A cable kits to connect from distribution boards to switches and attenuators.
 Y1150A 34945EXT distribution board for eight N181x SPDT switches
 Y1151A 34945EXT distribution board for two 87104x/106x multiport or 87406B matrix switches
 Y1152A 34945EXT distribution board for one 87204x/206x or 87606B switch and
two N181x switches
 Y1153A 34945EXT distribution board for two 84904/5/6/7/8 or 8494/5/6 step attenuators
 Y1154A 34945EXT distribution board for two 87222 transfer switches and six N181x SPDT switches
 Y1155A 34945A distribution board w/ generic screw terminals for driving 16 switch coils
 Y1156A Diagnostics board to verify switch control signals Recommended for troubleshooting purposes
 Y1157A 9-to-10 pin cable kit for Y1150A, Y1152A, Y1154A - supplies to build 4 cables
 Y1158A 10-to-10/10-to-14 pin cable kit for Y1153A, Y1154A - supplies to build 2 cables
 Y1159A 16-to-16 pin cable kit for Y1150A/51A/52A/53A/54A/55Asupplies to build 2 cables
L44xxA Accessories:
 Y1160A EIA Rack Sliding Shelf Installation Kit
Rack Mount kit for two L44xx series instruments
Thermocouples/Thermistors
 34307A 10 pack of J type thermocouples
 34308A 5 pack of 10k thermistors

**Module specifications include terminal block. Performance may be degraded when using cables or connector kits.
