The Oscilloscope Experience Redefined

Keysight InfiniiVision 4000 X-Series oscilloscopes

Keysight InfiniiVision 4000 X-Series OscilloscopesNo Other Oscilloscope Can Touch It

  • Experience the speed with the ability to find the most difficult problems in your design with 1 million waveforms/sec update rate, MegaZoom IV smart memory and standard segmented memory.
  • Experience the usability of the first oscilloscope designed for touch capability with the industry’s largest 12.1-inch capacitive touch display and innovative InfiniiScan Zone touch triggering.
  • Experience the integration of 5 instruments in one: oscilloscope, logic analyzer, serial protocol analyzer, WaveGen built-in dual channel arbitrary/function generator, and integrated 3-digit voltmeter, with the ability to upgrade your scope at any time for complete investment protection.

Keysight Technologies introduces the groundbreaking InfiniiVision 4000 X-Series digital-storage and mixed-signal oscilloscopes. This new series establishes unprecedented levels of flexibility and ease of use among units that use an embedded operating system.

The new lineup offers bandwidths from 200 MHz to 1.5 GHz and several benchmark features. First is an industry-leading update rate of one million waveforms per second with standard segmented memory, which uses patented MegaZoom IV smart memory technology. Next are a 12-inch capacitive touch screen—the industry’s largest—and the exclusive, all-new InfiniiScan Zone touch-triggering capability.

The hallmarks of the 4000 X-Series are speed, ease of use and integration. With the high-speed waveform update rate, operation is always fast, even with digital channels, protocol decoding, math functions or measurements activated. Speed also translates into the highest probability of capturing random or intermittent events that often go undetected by scopes with lower update rates.

Because the 4000 X-Series was designed specifically for touch operation, engineers can select targets naturally and quickly. For example, InfiniiScan Zone makes triggering as easy as finding the signal of interest and drawing a box around it: If users can see a signal, they can trigger on it. To further improve productivity, the interface includes an alphanumeric touchpad that replaces tedious knob-based operation, and touch-based interaction that enables greater flexibility in displaying measurement information.

The high level of integration starts with the capabilities of five instruments on one unit: oscilloscope, digital channels (MSO), protocol analysis, digital voltmeter and dual-channel WaveGen function/arbitrary waveform generator. The 4000 X-Series also supports a wide range of popular optional applications: MIL-STD 1553 and ARINC 429; I2S; CAN/LIN; FlexRay; RS232/422/485/UART; I2C/ SPI; and USB 2.0 Hi-Speed, Full-Speed and Low-Speed triggering and analysis (the first hardware-based USB trigger/decode oscilloscope solution).

4000 X-Series Bandwidth Channels

MegaZoom IV smart memory technology enables the speed, usablility and integration

DSOX4022A MSOX4022A 200 MHz 2/2+16
DSOX4024A MSOX4024A 200 MHz 4/4+16
DSOX4032A MSOX4032A 350 MHz 2/2+16
DSOX4034A MSOX4034A 350 MHz 4/4+16
DSOX4052A MSOX4052A 500 MHz 2/2+16
DSOX4054A MSOX4054A 500 MHz 4/4+16
DSOX4104A MSOX4104A 1 GHz 4/4+16
DSOX4154A MSOX4154A 1.2 GHz 4/4+16
