Keysight E36300 Series

Keysight's E36300 Series Triple Output Programmable DC Power Supplies

The E36300 Series DC power supplies are easy and intuitive to use with a full menu front panel interface. They include a 4.3" color LCD display, color-coded channels, individual voltage and current knobs, On/Off for all channels and keypad with soft-keys. Their quick configuration and simple operation these power supplies will improve productivity. Plus, the E36300 Series boasts modernized I/O with LAN (LXI Core) and USB, along with enhanced features like auto series/parallel, output sequencing, data-logging and more — making them effective power supplies on the bench. They are also supported by BenchVue.

Keysight E36311A

E36311A Triple Output Programmable 80 Watt DC Power Supply

  • 1 x 0 to 6 V, 0 to 5 A
  • 2 x 0 to ±25 V, 0 to 1 A
  • 3 x 0 to ±25 V, 0 to 1 A

Features:

  • Series voltage / Parallel current: 50 V / 4 A
  • 4.3-inch LCD color display
  • Color-coded channels
  • Individual knobs for voltage and current
  • All channels electrically-isolated w/ individual on/off
  • Low output ripple noise

On the bench, the triple output E36311A is ready for your application. With low output ripple/noise and accurate voltage/current measurement, you can test with confidence — and power your next insight.

Keysight E36312A

E36312A Triple Output Programmable 80 Watt DC Power Supply

  • 1 x 0 to 6 V, 0 to 5 A
  • 2 x 0 to ±25 V, 0 to 1 A
  • 3 x 0 to ±25 V, 0 to 1 A

E36313A Triple Output Programmable 160 Watt DC Power Supply

  • 1 x 0 to 6 V, 0 to 5 A
  • 2 x 0 to ±25 V, 0 to 2 A
  • 3 x 0 to ±25 V, 0 to 2 A

All the features of the E36311A, plus:

  • Series voltage / Parallel current: 50 V / 4 A
  • LAN (LXI), USB and optional GPIB
  • Front and rear output terminals
  • Fast transient response time: < 50 μs
  • Small current measurement: 80 μA
  • 4-wire remote sensing

  • {{product.altText}}
    {{product.shortDescription}}
    {{product.erpNumber}} MFG #: {{product.manufacturerItem}} My Part #: {{product.customerName}}
    / {{product.unitOfMeasureDescription || product.unitOfMeasureDisplay}}
    Please call for price: (800) 950-3457
    Add to List
E36300 Series
DC Power Supplies		 E36311A
80 Watts		 E36312A
80 Watts		 E36313A
160 Watts
DC Output:  1 2 3 1 2 3 1 2 3
0 to 6 V 0 to +25 V 0 to -25 V 0 to 6 V 0 to 25 V 0 to 25 V 0 to 6 V 0 to 25 V 0 to 25 V
0 to 5 A 0 to 1 A 0 to 1 A 0 to 5 A 0 to 1 A 0 to 1 A 0 to 10 A 0 to 2 A 0 to 2 A
Series mode voltage:  –   50 V     50 V
Parallel mode current:  –   2 A     4 A
I/O interface:  USB LAN, USB, optional GPIB LAN, USB, optional GPIB
Low Current Measurement: – µ µ
Output sequencing: – ▀ ▀
Output LIST Capability: – ▀ ▀
Data logging: – ▀ ▀
Remote sensing: – ▀ ▀
Rear output terminals: – ▀ ▀
