Keysight FieldFox Microwave Spectrum Network Analyzers

Keysight FieldFox Microwave Spectrum Network Analyzers - to 50 GHz

FieldFox microwave spectrum analyzers provide industry-leading amplitude accuracy of ±0.5 dB at power-up, with no warm-up required, allowing field users to instantly and precisely characterize transmitter power. They can detect more signals in the band of interest with phase noise of -111 dBc/Hz at 10 kHz offset, and measure low-level signals in the presence of high-power transmitters with spur-free dynamic range of 105 dB.

N993X FieldFox Microwave Spectrum Analyzers

Carrying precision into difficult environments

The spectrum analyzer’s base function is spectrum analysis, and can be configured to include; full-band tracking generator and preamplifier, interference analyzer, VSWR and reflection measurements, built-in power meter, USB power sensor support, GPS receiver and DC bias voltage source. Key options include: full-band tracking generator, full-band preamplifier, interference analyzer & spectrogram, reflection measurements, and built-in power meter.  Download FieldFox Selection Guide.
>> Limited-time Trade-in Offer - Get info!

Model Spectrum Analyzer Frequency Base Price
N9935A 5 kHz to 9 GHz $16,220
N9936A 5 kHz to 14 GHz $19,576
N9937A 5 kHz to 18 GHz $23,490
N9938A 5 kHz to 26.5 GHz $27,406
N9960A 5 kHz to 32 GHz $33,032
N9961A 5 kHz to 44 GHz $44,386
N9962A 5 kHz to 50 GHz $56,773

MIL-PRF-28800F Class 2 compliant, MIL-STD-810G, Method 511.5 Procedure I requirements for operation in explosive environments (type tested), Three-year warranty.

• Visit FieldFox Handheld Analyzer Selection Guide to see all Keysight FieldFox models, and to download application notes.

FieldFox Handheld Microwave Analyzers now offer I/Q Analyzer mode

IQ Analysis is the ideal capturing tool to verify final signal chain integration or troubleshoot signal quality degradation due to hardware or software issues. The FieldFox I/Q analyzer mode (Option 351) provides frequency and time domain measurements and customizable multi-domain display views. I/Q data can also be captured on the instrument and analyzed using 89600 VSA Software, MATLAB, Python tool kit and other third party demodulation software. Additionally, I/Q capture data of an RF signal environment can be re-generated and played back using a vector signal generator. FieldFox I/Q Analyzer mode supports 10 MHz of analysis bandwidth and requires the spectrum analysis option (not supported on model N9912A).
