Keysight InfiniiVision 2000 X-Series Oscilloscopes
Get measurements you can count on!

The InfiniiVision 2000 X-Series offers entry-level price points to fit your budget with superior performance and optional capabilities that are not available in any other oscilloscope in its class. This Keysight Technologies, Inc. breakthrough technology delivers more scope for the same budget.

InfiniiVision 2000 X-Series Oscilloscopes

  • 70 MHz to 200 MHz
  • See more signal detail with 200,000 wfms/s update rate
  • View time-correlated digital content with 8 digital channels (MSO)
  • Modulate signals within the scope with WaveGen, built-in 20 MHz function generator (optional)
  • Quickly characterize signals with the built-in 3-digit voltmeter and 5-digit counter
  • Decode serial busses faster with hardware-based serial analysis options for CAN, LIN, I2C, SPI and RS232/422/485/UART
  • Protect your investment with full upgradability

More Scope?

• See more of your signal more of the time with the largest screen in its class, the deep memory and the fastest waveform update rates
• Do more with the power of 5 instruments in 1:Oscilloscope, logic timing analyzer, WaveGen built-in 20 MHz function generator (optional), serial protocol triggering and decode (optional), and digital voltmeter
• Get more investment protection with the classes only fully upgradable scope.

Model Description Bandwidth Channels Max Memory Depth Max Sample Rate
DSOX2002A Digital Storage Oscilloscope 70 MHz 2 1 Mpts 2 GSa/s
MSOX2002A Mixed Signal Oscilloscope 70 MHz 2 + 8 1 Mpts 2 GSa/s
DSOX2004A Digital Storage Oscilloscope 70 MHz 4 1 Mpts 2 GSa/s
MSOX2004A Mixed Signal Oscilloscope 70 MHz 4 + 8 1 Mpts 2 GSa/s
DSOX2012A Digital Storage Oscilloscope 100 MHz 2 1 Mpts 2 GSa/s
MSOX2012A Mixed Signal Oscilloscope 100 MHz 2 + 8 1 Mpts 2 GSa/s
DSOX2014A Digital Storage Oscilloscope 100 MHz 4 1 Mpts 2 GSa/s
MSOX2014A Mixed Signal Oscilloscope 100 MHz 4 + 8 1 Mpts 2 GSa/s
DSOX2022A Digital Storage Oscilloscope 200 MHz 2 1 Mpts 2 GSa/s
MSOX2022A Mixed Signal Oscilloscope 200 MHz 2 + 8 1 Mpts 2 GSa/s
DSOX2024A Digital Storage Oscilloscope 200 MHz 4 1 Mpts 2 GSa/s
MSOX2024A Mixed Signal Oscilloscope 200 MHz 4 + 8 1 Mpts 2 GSa/s

Downloads:
InfiniiVision 2000 X-Series Product Fact Sheet
InfiniiVision 2000 X-Series Data Sheet
