Keysight InfiniiVision 6000 X-Series Oscilloscopes
Take advantage of unprecedented visualization power.
The 6000 X-Series is designed for engineers who need bandwidth, visualization power, and the flexibility that comes with integrated capabilities. Get unprecedented visualization power with 450,000 waveforms / second update rate coupled with the hardware-based zone touch trigger. Increase your productivity with its 7-in-1 instrument integration and multi-language voice control.
InfiniiVision 6000 X-Series Oscilloscopes
- 1 GHz to 6 GHz, DSO or MSO models
- See more signal detail with 450,000 wfms/s update rate
- Isolate signals in seconds with exclusive Zone Touch Triggering
- Operate hands-free with multi-language voice control
- Get more functionality with optional integrated digital channels, serial protocol analysis, dual-channel WaveGen and 10-digit counter + 3-digit voltmeter
- Protect your investment with full upgradability; add options and bandwidth at any time
Get maximum bandwidth and superior signal integrity
• more precise measurements with low noise, enabled by a new front-end ASIC
• 115-μVrms noise floor at 1 mV/div at 1-GHz bandwidth
• Speed debugging with the combination of segmented memory and serial protocol trigger and decode
| Model | Description | Bandwidth | Channels | Max Memory | Max Sample Rate | Waveform Update Rate |
| DSOX6002A | Digital Storage Oscilloscope | 1 GHz to 6 GHz | 2 | 4 Mpts | 20 GSa/s | 450,000 wfms/sec |
| MSOX6002A | Mixed Signal Oscilloscope | 1 GHz to 6 GHz | 2 + 16 | 4 Mpts | 20 GSa/s | 450,000 wfms/sec |
| DSOX6004A | Digital Storage Oscilloscope | 1 GHz to 6 GHz | 4 | 4 Mpts | 20 GSa/s | 450,000 wfms/sec |
| MSOX6004A | Mixed Signal Oscilloscope | 1 GHz to 6 GHz | 4 + 16 | 4 Mpts | 20 GSa/s | 450,000 wfms/sec |
Downloads:
InfiniiVision 6000 X-Series Product Fact Sheet
InfiniiVision 6000 X-Series Data Sheet
