Keysight Knows Power - B2900B Series

Keysight Knows Power.

The Keysight B2900 Series Precision Bench-top Instrument Family includes several different source and measurement solutions. It currently consists of the Precision Source/Measure Units (SMUs), the Precision Low Noise Power Sources and the Femto / Picoammeters and Electrometers / High Resistance Meters.

The B2900 Family provides best-in-class source and measurement performance along with other powerful capabilities. In addition it has broad applications that cover the range from R&D and education to industrial development, production test and automated manufacturing. They also work equally well as either standalone or system components.

Model	Description
B2901B	Precision SMU 1 Channel 100 fA Resolution 210 V 3 ADC 10.5 A Pulse
B2901BL	Precision SMU 1 Channel 1 pA Resolution 210 V 1.5 A Pulse
B2902B	Precision SMU 2 Channel 100 fA Resolution 210 V 3 ADC 10.5 A Pulse
B2910BL	Precision SMU 1 Channel 10 fA Resolution 210 V 1.5 A Pulse
B2911B	Precision SMU 1 Channel 10 fA Resolution 210 V 3 ADC 10.5 A Pulse
B2912B	Precision SMU 2 Channel 10 fA Resolution 210 V 3 ADC 10.5 A Pulse
B2961B	Low Noise Power Source 1 Channel 100 nV/10 fA Resolution 210 V 3 A 32 W 6.5 Digit
B2962B	Low Noise Power Source 2 Channel 100 nV/10 fA Resolution 210 V 3 A 32 W 6.5 Digit

Use this PathWave BenchVue software to easily track and record your power supply outputs so you can understand events impact on power usage.

PathWave BenchVue BV9200B Advanced Power Control and Analysis Software Supports one instrument
Easily track and record your power supply outputs to understand events impact on power usage
Graphically configure three modes of analysis: scope (short-term waveform capture), data logger (long-term waveform capture), and CCDF (statistical analysis)
Easily create complex waveforms to stimulate or load down a DUT by inputting a formula, choosing from built-in, or importing waveform data
