Keysight RF Power Meters

Keysight RF Power Meters - Authorized Keysight Distributor - Fast Delivery

Learn more on how to select the right power meter and power sensors

Keysight power meters operate with sensors of various types (CW, average and peak and average), covering numerous frequency and power ranges to accurately measure the power of RF and microwave signals. Applications include testing the output power of communication base-station transmitters, cellular telephones, radar system equipment, and much more.

Selection Guides and Measurement Tips

Power Meter and Sensor Selection Guide (pdf, 2M)
Power Meter and Sensor Portfolio (pdf, 2M)
FieldFox Measurement Options
Click Here for Measurement Tips

Demos

USB Power Sensors Demo Guide (pdf, 2.4M)

Now available for sale to all customers within the US and Canada!

Keysight Power Meter Selection - Click the model for more information or to order online.

Model Channels Power Range Speed Power Sensors Features
Keysight 8990B Peak Power Analyzer
8990B
Peak Power Analyzer
4 N1923A Sensors 50 MHz - 18 GHz
N1924A Sensors 50 MHz - 40 GHz
more than 1500
readings/sec
N1921A
N1922A
N1923A
N1924A
RF pulses, Rise time, fall time, minimum, average, peak
Keysight E4416A
E4416A EPM-P Series
1 E9320 Sensors -65 dBm to +20 dBm
E9300 Sensors -60 dBm to +44 dBm
E441XA CW Sensors -70 dBm to +20 dBm
8480 Sensors -70 dBm to +44 dBm
up to 1000
readings/sec

8480 Series
E441xA Series
E9320 Series
E9300 Series

peak, average and time-gated power
Keysight E4417A
E4417A EPM-P Series
2 E9320 Sensors -65 dBm to +20 dBm
E9300 Sensors -60 dBm to +44 dBm
E441XA CW Sensors -70 dBm to +20 dBm
8480 Sensors -70 dBm to +44 dBm
up to 1000
readings/sec

8480 Series
E441xA Series
E9320 Series
E9300 Series

peak, average and time-gated power
Keysight N1913A
N1913A EPM Series
1

U2000 Sensors -60 dBm to +44 dBm
N8480 Sensors -70 dBm to +44 dBm
8480 Sensors -70 dBm to +44 dBm
E441XA CW Sensors -70 dBm to +20 dBm
E9300 Sensors -60 dBm to +44 dBm

up to 400
readings/second

U2000 Series
N8480 Series
8480 Series
E4410A Series
E9300 Series
Not E932X Series

average power

Keysight N1914A
N1914A EPM Series

2 U2000 Sensors -60 dBm to +44 dBm
N8480 Sensors -70 dBm to +44 dBm
8480 Sensors -70 dBm to +44 dBm
E441XA CW Sensors -70 dBm to +20 dBm
E9300 Sensors -60 dBm to +44 dBm
up to 200
readings/second
on each channel

U2000 Series
N8480 Series
8480 Series
E4410A Series
E9300 Series
Not E932X Series

average power
Keysight N1911A
N1911A P-Series
1 N1920 Sensors -35 to +20 dBm
E9320 Sensors -65 to +20 dBm
E9300 Sensors -60 to +44 dBm
E441XA Sensors -70 to +20 dBm
8480 Sensors -70 to +44 dBm
> 1500
readings/second

8484 Series
8480 Series
E441xA Series
E9320 Series
E9300 Series
N192xA Series

Peak, pk-to-avg, average power, rise/fall time measurements, Internal zeroing and calibration, 30 MHz video BW, 100 MSa/s continuous sampling.
Keysight N1911A
N1912A P-Series
2 N1920 Sensors -35 to +20 dBm
E9320 Sensors -65 to +20 dBm
E9300 Sensors -60 to +44 dBm
E441XA Sensors -70 to +20 dBm
8480 Sensors -70 to +44 dBm
> 1500
readings/second

8484 Series
8480 Series
E441xA Series
E9320 Series
E9300 Series
N192xA Series

Peak, pk-to-avg, average power, rise/fall time measurements, Internal zeroing and calibration, 30 MHz video BW, 100 MSa/s continuous sampling.
Keysight N8262A
N8262A P-Series
2 N1920 Sensors -35 to +20 dBm
E9300 Sensors -60 to +44 dBm
E441XA Sensors -70 to +20 dBm
8480 Sensors -70 to +44 dBm
> 1500
readings/second

8484 Series
8480 Series
E441xA Series
E9320 Series
E9300 Series
N192xA Series

LAN-based automated measurements, Peak, pk-to-avg, average power, rise/fall time measurements, Internal zeroing and calibration, 30 MHz video BW, 100 MSa/s continuous sampling.
Keysight U2000 Series
U2000 Series
n/a -60 dBm to +44 dBm 1000
readings/second
Direct reading
via USB

USB interface. Internal zeroing capability. Display power measurements on a PC or other Keysight instruments. True average power measurement.

Keysight U2021XA USB Power Sensor
U2021XA
n/a -30 to +20 dBm (peak/gated)
-35 to +20 dBm (average)
> 3500 readings/sec Direct reading
via USB
Freq. range: 50 MHz to 18 GHz
30 MHz video bandwidth
Internal zeroing & calibration
N-Type (m) connector
Keysight U2022XA USB Power Sensor
U2022XA
n/a -30 to +20 dBm (peak/gated)
-35 to +20 dBm (average)
> 3500 readings/sec Direct reading
via USB
Freq. range: 50 MHz to 40 GHz
30 MHz video bandwidth
Internal zeroing & calibration
2.4 mm (m) connector.
Keysight V3500A Handheld RF Power Meter
V3500A
Handheld RF Power Meter
1 -63 dBm to +20 dBm 23 readings
per second
Integrated power sensor 10 MHz to 6 GHz frequency range
Internal power reference enable self calibration
USB interface for remote programming / data logging

Keysight Power Sensor Selection - Click the model for more information or to order online.

U2000 Series USB Average Power Sensor
U2000 Series USB Average Power Sensor enable fast, simple setup by providing plug-and-play USB connectivity and by eliminating the need for a separate power meter.

E441XA CW Power Sensors
Operates with the EPM, EPM-P and P-series power meters. Wide dynamic range -70 dBm to +20 dBm. 10 MHz to 26.5 GHz (sensor dependent). Calibration factors stored in EEPROM.

8480 Series Power Sensors
The 8480 series power sensors are designed for use with the EPM, EPM-P, P-series, 70100A and E1416A power meters, and operate over 100 kHz to 110 GHz, -70 to +44 dBm.

E8486A, V8486A, W8486A Waveguide Power Sensors
The E8486A makes precise and direct waveguide measurements in the E-band frequency range and is compatible with most Keysight power meters. They feature a wide dynamic range of -60 to +20 dBm and a SWR performance of 1.06.

E9300 Average Power Sensors
Operates with the EPM, EPM-P and P-series power meters. Wide dynamic range sensors (80 dB maximum). Accurate average power measurements on all modulation formats. 9 kHz to 18 GHz (special option to 24 GHz). Calibration factors stored in EEPROM.

E9320 Peak and Average Power Sensors
Operates with the EPM-P series and P-Series power meters. 300 kHz, 1.5 MHz and 5 MHz video (modulation) bandwidths. Calibration factors stored in EEPROM. 50 MHz to 6 GHz, and 50 MHz to 18 GHz. Wide dynamic range.

N8480 Series Power Sensors
N8480 Series Power Sensors are the latest thermocouple sensors from Keysight with excellent measurement accuracy, repeatability and linearity. 100 kHz up to 50 GHz. 55 dB wide dynamic range. Built-in EEPROM features for easy calibration. Compatible with EPM (E4418B/19B, N1913A/N1914A), EPM-P (E4416A/17A) and P-Series (N1911A/12A) power meters.

P-Series Wideband Power Sensors
The Keysight P-Series wideband power sensors provides peak, peak-to-average ratio, average power, rise time, fall time, maximum power, minimum power and statistical data of wideband signals. Zero and calibrate while connected to the DUT. 50 MHz to 40 GHz. Wide dynamic range, -35 dBm to +20 dBm.

Wideband Power Sensors
The N1923A and N9124A wideband power sensors are the first to provide internal zero and calibration by integrating a DC reference source and switching circuits into the power sensor. This feature eliminates the multiple connections associated with using an external calibration source, thus minimizing connector wear, test-time and measurement uncertainty.


Measurement Tips and Technical Resources.

Keysight Power Meters and Power Sensors Selection Guide

U2000 Series USB Power Sensors GSM Timeslot Burst Power Measurement

Scalar Network Analysis with U2000 Series USB Power Sensors

Seven Practices to Prevent Damaging Power Meters and Power Sensors
