Keysight USB Modular Instruments: U2701A, U2702A, U2722A, U2723A, U2741A, U2751A, U2761A, U2781A

Keysight USB Modular Instruments

Keysight's growing family of USB-based modular instruments now includes oscilloscopes, a function generator, source measure unit and switch matrix, while the series of data acquisition family consists of numerous modules. This makes electronic functional test, troubleshooting, data logging and measurement effortless. These devices offer the flexibility of standalone or modular operation for easy, affordable measurements and analysis. Kick start your measurements with a USB interface to your PC and the easy-to-use, feature-packed software bundled with each instrument.

Keysight USB Modular Instruments: U2701A, U2702A, U2722A, U2723A, U2741A, U2751A, U2761A, U2781A

Keysight USB Modular Instruments

U2701A USB Modular Oscilloscope, 100 MHz
Keysight U2701A is a 2 channel 8-bit 100MHz Oscilloscope. It uses the common non-proprietary standard high-speed USB 2.0 interface that provide ease of connectivity.

U2702A USB Modular Oscilloscope, 200 MHz
Keysight U2702A is a 2 channel 8-bit 200 MHz Oscilloscope. It uses the common non-proprietary standard high-speed USB 2.0 interface that provide ease of connectivity.

U2722A USB Modular Source Measure Unit
U2722A is a SMU that can operate in a 4-quadrant operation. The channels could be connected in series/in parallel for higher power. The optional Keysight U2941A parametric test fixture complements the U2722A in the testing of semiconductor components.

U2723A USB Modular Source Measure Unit
The U2723A USB Modular Source Measure Unit is a 3-channel 20V/120mA that can operate in a 4-quadrant operation. It has embedded test scripts that will simplify automated testing with up to two test scripts per channel.

U2741A USB Modular Digital Multimeter, 5.5 digit
Keysight U2741A USB Modular Digital Multimeter is a small form factor multimeter with huge capabilities. It provides a broad range of measurement functions, including temperature and frequency.

U2751A 4x8 2 Wire USB Modular Switch Matrix
Keysight U2751A USB Modular Switch Matrix offers a flexible connection path between the device under test and test equipment, thus allowing different instruments to be connected to multiple points on the device under test at the same time.

U2761A USB Modular Function Generator
Keysight U2761A is a 20 MHz function generator that offers 10 standard waveforms plus pulse and arbitrary waveforms generation capabilities.

U2781A USB Modular Instrument Chassis
The U2781A USB modular instrument chassis is AC powered and compact. The U7261A can house up to six Keysight U2300A Series USB modular instruments.
