Keysight Function/Arbitrary Waveform Generator Selection Guide

Keysight Function/Arbitrary Waveform Generator Selection Guide

Get the latest information about new product introductions and special pricing.
Subscribe to the TestEquity Email Newsletter HERE.

Model Waveform & Modulation Frequency Range Arbitrary Waveforms Connectivity Type

Keysight 33600A Series

33600 A Series

The 33600A Series, with Trueform Technology, provides 4 upgradable models in 80 and 120 MHz, 1- or 2-channels, Trueform arbs with sequencing and 64 MSa memory, 1 ps jitter (1/100th the jitter of DDS generators) and 5x lower harmonic distortion than DDS generators. 80 MHz
120 MHz
up to 64 MSa memory
  • LAN
  • USB
  • GPIB
Function/Arbitrary Waveform Generators

Keysight 33500B Series

33500B Series

Function/Arbitrary Waveform Generators, Up to 30 MHz sine and pulse. Keysight exclusive Trueform Technology (learn more), Sine, square, ramp, pulse, triangle, Gaussian noise, PRBS (Pseudorandom Binary Sequence), DC, Cardiac, exponential fall, exponential rise, Gaussian pulse, Haversine, Lorentz, D-Lorentz, negative ramp, sinc 20 MHz or 30 MHz 16 bits, 1 μSa/s to 250 MSa/s
  • LAN
  • USB
  • GPIB
Function/Arbitrary Waveform Generators

Keysight 33210A

33210A

Function/Arbitrary Waveform Generator, 10 MHz Sine, square, triangle, ramp, pulse, noise, DC volts, AM, FM,PWM, Built-in Arbitrary Waveforms (OPTIONAL): exponential rise & fall, sin(x)/x, cardiac, arbitrary 10 MHz OPTIONAL
14 bits, 8 K points, 50 MSa/s
  • GPIB
  • LAN
  • USB
Function/Arbitrary Waveform Generator

Keysight 33502A

33502A

Dual-channel amplifier, companion for function generators <1 MHz n/a
  • LAN
  • USB
Amplifier

Keysight U2761A

U2761A

Function/Arbitrary Waveform Generator, 20 MHz Sine, square, triangle, ramp, pulse, sin(x)/x, exponential rise & fall, DC volts, arbitrary, AM,FM,PM,ASK,FSK,PSK 20 MHz 14 bits, 64K points, 50 MSa/s (200 kHz)
  • USB
Function/Arbitrary Waveform Generator

Keysight 33503A

33503A

BenchLink Waveform Builder Pro software provides quick access to common signals (sine, square, triangle, ramp, pulse, exponential). This Microsoft Windows-based program provides easy-to-use arbitrary waveform creation tools and libraries of advanced signals, waveform sequencing, equation editor, signal filtering and windowing functions.
