Keysight N6791A / N6792A DC Electronic Load Modules

Measure More with Less

Mix and Match over 30 Power Supply Modules with new Electronic Loads in the same N6700C Mainframe
From making battery drain test analysis to measuring DC-DC converter efficiency, now you can do it with fewer instruments on your bench. Keysight now offers 1U height modular electronic load modules for the N6700 modular power supply family. These new modules are ideal as they incorporate the modular flexibility of Keysight's existing N6700C low profile platform. For the first-time you can combine power supplies and electronic loads in the same ecosystem while allowing preservation of precious rack space.

N6790 Series Electronic Loads

N6790 Series Electronic Loads

N6791A: 100 W, 1U, single wide
N6792A: 200 W, 1U, double-wide



A Must-have for Power System Designers and Test Engineers
The new Keysight N6790 Series Modular Electronic Loads offer a 100W module and a 200W module — each in a 1U footprint. Four different user operation modes are available: constant voltage, constant current, constant resistance, and constant power. With a highly-accurate measurement system and digitizing capabilities, you can easily gain insight into power supply tests. Also, the N6791A and N6792A offer a powerful, built-in arbitrary waveform generator which allows you to emulate complex dynamic load waveforms.

  • Input: N6791A 100 W, 20 A, 60 V, single-wide  |  N6792A 200 W, 40 A, 60 V, double-wide
  • Modes: Constant Voltage, Constant Current, Constant Resistance, Constant Power
  • USB, LAN, GPIB interfaces standard
  • N6700 style UI for ease of use and familiarity

Use with N6705C Mainframe
You can get a powerful built-in arbitrary generator that allows you to emulate complex dynamic waveforms. Analyze and report data with built-in data logger that helps in generating reports for your applications. The N6790 Series electronic load modules are easily configurable on N6705C DC Power Analyzer or N6700/01/02C Low Profile Mainframes.

  • Bench – Configure N6705C DC Power Analyzer Mainframe with N6790 Series Electronic Load module or with any of DC Power Supply Modules
  • System – Configure N6700/01/02C Low Profile Mainframes with N6790 Series Electronic Load Modules or with any of DC Power Supply Modules.

N6705C DC Power Analyzer Mainframe

N6705C DC Power Analyzer Mainframe

600 W, 4 power supplies integrated
with DMM, Scope, Arb, Datalogger

N6700 Series Power Supply Modules

N6700 Series Power Supply Modules

38 basic, high-performance, precision, electronic load, and source/measure modules

N6700C Modular Power Supply System

N6700C Modular Power Supply System

Up to 1200 W multiple output
programmable DC power supply system
