Demo Request: Rohde & Schwarz Oscilloscopes, Spectrum Analyzer and Vector Network Analyzer

Five instruments in one handheld package
The perfect multipurpose tool for the lab or field

• Lab performance oscilloscope
• To 500 MHz
• Isolated, CAT IV
• Logic analyzer
• Protocol analyzer
• Data logger
• Digital multimeter

High-resolution display in a compact form

• 4-ch.; 200 MHz (upgradable to 1 GHz)
• 10-bit vertical resolution
• 5 Gsample/s (interleaved)
• 10.1" capacitive touch, 1280 x 800 px.
• Logic analyzer, protocol analyzer, spectrum analyzer, waveform and pattern generator. counter and DVM

aSeries Digital Oscilloscope
See small signal details in the presence of large signals

• 2-/4-channels; 70 MHz (upgradable)
• 10-bit vertical resolution
• 1 mV/div: full measurement bandwidth and low noise

Versatile measurement functions and fast results

• 50 MHz (upgradable to 300 MHz)
• 8-bit vertical resolution
• 2-channels + 8 digital ch (w/MSO opt.)
• Eight-in-one instrument
• Wide range of upgrade options

Truly uncompromised performance

• 2- or 4-ch.; 200 MHz to 2 GHz
• MSO Option for 16 digital channels
• 5 Gsample/s on all channels
• 10.4" TFT (XGA) touchscreen
• High definition mode with up to 16-bit vertical resolution

High-resolution display in a compact form

• 100 MHz (upgradable to 1 GHz)
• 10-bit vertical resolution
• 2 or 4 ch + 16 digital ch (w/MSO opt.)
• Memory depth: 40/80 Msample
• More than just an oscilloscope

High-resolution display in a compact form

• 600 MHz (upgradable to 6 GHz)
• Up to 16-bit vertical resolution
• 2 or 4 ch + 16 digital ch (w/MSO opt.)
• 10 GS/s Sample Rate
• Memory depth: up to 800MSa
• 1.000.000 waveforms/s

Unexpected performance in its class

• First Wi-Fi-enabled in its class
• Innovative control - fast and easy w/ control w/ iOS/Android/PC software
• Lab feature in R&S InstrumentView - set-up a wireless remote lab in minutes

More than just a "standard-performance" VNA

• 5 kHz to 3/6 GHz frequency range
• Fast, reliable and intuitive
• Portable / Battery Operation

Compact plug-and-play vector network analyzer

• 1 MHz to 3/6 GHz frequency range
• Two ports
• Standalone instrument with 10.1" WXGA touchscreen
