Sorensen Bench DC Power Supplies



TestEquity is an authorized Distributor for Sorensen Power Supplies
(Bench DC Power Supplies)

Xantrex DC Power Supplies are now sold under the Sorensen brand name.

Sorensen Bench DC Power Supplies Sold and Stocked by TestEquity:
Click the product links for more information, pricing, or to order online.

 Sorensen XHR Series Programmable DC Power Supplies - 1000 Watts

  • Power factor correction (0.99 min.), High efficiency, 85% typical
  • Zero voltage ("soft") switching for high efficiency and low noise
  • 85 to 250 VAC universal input
  • 10-turn voltage and current control
  • Constant voltage, constant current
  • Adjustable overvoltage protection
  • LED voltmeter and ammeter
  • Remote sensing and programming
  • Output current/voltage monitor
  • Front panel standby switch
  • Remote on/off
  • Optional GPIB or RS-232

Sorensen XPD Series Programmable DC Power Supplies - Up to 540 Watts

  • Power factor correction (0.98 min.)
  • Zero voltage "soft" switching for high efficiency and low noise
  • 85 to 264 VAC universal input
  • High efficiency, >80%
  • 10-turn voltage and current control
  • Constant voltage, constant current
  • Adjustable overvoltage protection
  • LED voltmeter and ammeter with bargraph
  • Remote sensing and analog programming
  • Output current/voltage monitor
  • Remote on/off
  • Optional GPIB or RS-232
Sorensen XPF Series Programmable DC Power Supplies - Up to 420 Watts (X2)

Sorensen XPF Series Programmable DC Power Supplies - Up to 420 Watts (X2)

  • XPF35-10: 0-35 V, 10 A or 175 W max. each output
  • XPF60-20: 0-60 V, 20 A or 420 W max. each output
  • Dual isolated outputs
  • Constant voltage or constant current
  • Coarse & fine voltage controls
  • Switching pre-regulator, linear post-regulator
  • Remote sensing
  • Overvoltage protection
  • Power factor correction
  • Optional RS-232, USB, GPIB or LAN

Sorensen HPD Series Programmable DC Power Supplies - 300 Watts

  • Constant voltage, constant current
  • LED voltmeter and ammeter with bargraph
  • Remote sensing
  • Rack mount capability
  • 10-turn voltage control, 1-turn (optional 10-turn) current control
  • Constant voltage, constant current
  • Optional internal analog programming, OVP
  • Optional GPIB or RS-232

Sorensen XPH Series Programmable DC Power Supplies - 175 to 420 Watts

  • Single, dual, and triple models
  • Constant voltage or constant current
  • Coarse & fine voltage controls
  • Individual ON/Off switch per output (not including fixed output on triple)
  • Regulation <0.01%

Sorensen XDL Series Precision DC Power Supplies - 105 to 215 Watts

  • Constant voltage or constant current
  • All linear regulation, <0.01%
  • Resolution 1 mV, 1 mA or 0.1 mA
  • Ripple <0.35 mV rms
  • Keypad or knob entry
  • Remote sensing
  • Stores 10 settings (30 on XDL35-5T)
  • Tracking, series or parallel mode on XDL35-5T (main outputs only)
  • OVP and OCP with alarm output
  • GPIB, RS-232, USB Interface ("P" Models)

Sorensen XEL Series Programmable DC Power Supplies - 75 to 180 Watts

  • 75 W to 180 W
  • Linear regulation
  • Single and dual output models
  • Ideal for engineering lab use
  • Digital features with analog controls
  • S-Lock: Set and lock the voltage
  • V-Span: user-defined voltage limits
  • "P" models have RS-232, USB & LAN (LXI-C)
  • "PG" models have GPIB, RS-232, USB & LAN (LXI-C)

Sorensen XBT32-3FTP Programmable DC Power Supply - Up to 126 Watts

  • Two 0-32 V, 0-3 A outputs (96 Watts max
  • One 0-15 V, 0-5 A output (30 Watts max)
  • High resolution, 16-bit programming and readback
  • Isolated, tracking, parallel or series operation
  • 100 hour timer function
  • USB and RS-232 Standard
  • Optional GPIB and Ethernet

Sorensen XPL Series Programmable DC Power Supplies - 30 to 125 Watts

  • Single, dual and triple models
  • Constant voltage or constant current
  • Coarse & fine voltage controls
  • Individual on/off switch per output (not including fixed output on Triple)
  • All linear regulation, <0.01%
  • Convection cooling, no fans

Sorensen XT Series Programmable DC Power Supplies - 60 Watts

  • LED voltmeter and ammeter with bargraph
  • Remote sensing
  • Rack mount capability
  • 10-turn voltage control, 1-turn (optional 10-turn) current control
  • Constant voltage, constant current
  • Optional analog programming, GPIB, or RS-232
Series Voltage Current Power Description
XT Series 7V - 250V 0.25A - 6A 60W Programmable linear DC power in a quarter-rack package
XPL Series 18V - 56V 1A - 3A 30W - 125W Economical and compact benchtop power supply
XEL Series 15V - 250V 1.5A - 6A 75W - 180W User-friendly 90W Linear Benchtop Supply
XDL Series 35V - 56V 1A - 5A 105W - 215W Digitally-controlled benchtop power supply
XBT Series 15V - 32V 3A - 5A 222W True triple output digital benchtop power supply
XPF35-10
XPF60-20
35V - 60V 10A - 20A 175W - 840W Benchtop power supply featuring dual isolated outputs.
HPD Series 15V - 60V 5A - 20A 300W 300 Watts in a quarter-rack wide chassis
XPH Series 18V - 150V 2A - 10A 175W - 420W Compact, high performance low cost power supply
XPD Series 8V - 120V 5A - 67A 0 - 500W 1/4 Rack Programmable DC Power Supplies
XHR Series 7V - 600V 1A - 130A 0 - 1000W 1000 watts of DC power in a compact half-rack package
