MSO64: More Speed. Lowest Noise. Exceptional Measurement Confidence.
Saves Embedded Systems Designers Time, Protects Investments
The new 6 Series MSO extends the performance threshold of midrange oscilloscopes to 8 GHz and delivers a 25 GS/s sample rate simultaneously on all 4 channels. The MSO64 also boosts measurement confidence with its low-noise inputs especially at the highest sensitivity settings where it matters most. For example, modern embedded designs require clean, precisely-controlled DC power supplies to feed ASIC and FPGA devices. For such applications, the 6 Series MSO enables designers to measure DC power rails with more resolution and accuracy, reducing the time it takes to understand high frequency influencers on power rails in a design.
FlexChannel® Technology Enables Maximum Flexibility and Broader System Visibility
The 6 Series MSO redefines what a Mixed Signal Oscilloscope (MSO) should be. FlexChannel technology enables each of the inputs on the instrument to be used as a single analog channel or eight digital channels. The conversion is done by simply attaching a TLP058 logic probe to any input. Imagine the flexibility and configurability this provides. You can change the configuration at any time by simply adding or removing TLP058 logic probes, so you always have the right number of digital channels. You can connect as many TLP058 probes as you like, enabling up to a maximum of 32 digital channels.
Unprecedented Signal Viewing Capability
The stunning 15.6" (396 mm) display in the 6 Series MSO is the largest display in the industry. It is also the highest resolution display, with full HD resolution (1,920 x 1,080), enabling you to see many signals at once with ample room for critical readouts and analysis. The viewing area is optimized to ensure that the maximum vertical space is available for waveforms. And it employs the touch interactions that you use with phones and tablets, and expect in a touch enabled device:
- Drag waveforms left/right or up/down to adjust horizontal and vertical position or to pan a zoomed view
- Pinch and expand to change scale or zoom in/out in either horizontal or vertical directions
- Drag items to the trash can to delete them
- Swipe in from the right to reveal the Results Bar or down from the top to access the menus in the upper left corner of the display
Windows or Not - You Choose
The 6 Series MSO offers you the choice of whether to include a Microsoft Windows™ operating system. Opening an access panel on the bottom of the instrument reveals a connection for a solid state drive (SSD). When the SSD is not present, the instrument boots as a dedicated scope with no ability to run or install other programs.
|MSO64 6-BW-1000||1 GHz|
|MSO64 6-BW-2500||2.5 GHz|
|MSO64 6-BW-4000||4 GHz|
|MSO64 6-BW-6000||6 GHz|
|MSO64 6-BW-8000||8 GHz|
