The Arbitrary/Function Generator Redefined

Tektronix AFG31000 Series Arbitrary Function Generators are Designed for High-Performance and Versatility.

Debug, Troubleshoot, Validate, and Characterize Your Designs
Tektronix has redefined the arbitrary/function generator with the new AFG31000 Series — a powerful, affordable, and easy-to-use AFG. It offers real-time waveform monitoring, optional programmable waveform sequencing, and the industry’s first AFG touchscreen to significantly boost productivity and efficiency.

Save Time and Effort with the Nine-Inch TouchScreen
The AFG31000 Series features the industry’s largest AFG touchscreen; pinch, zoom, and scroll just like a smart device to easily locate settings and parameters on the simple menu or shortcuts to frequently-used settings.

Verify Your WaveForm at the Device under Test
Patented InstaView™ technology lets you see the actual waveform at the device under test (DUT) in real time – without an oscilloscope or probe – eliminating any uncertainty typically caused by mismatched impedance.

Generate Multiple WaveForms with Complex Timing
Advanced waveform generation and programming capabilities make it easy to compose a list or a sequence of 1 to 256 waveforms with total waveform length up to 16 Mpts/ch (128 Mpts/ch optional) and define the output sequence of these waveforms.

Create and Edit Arbitrary WaveForms on the AFG
The built-in ArbBuilder editing tool includes everything you need to create, edit, and transfer an ARB waveform without the need to connect to a PC.

AFG31000 Series Arbitrary/Function Generators
The built-in ArbBuilder editing tool includes everything you need to create, edit, and transfer an ARB waveform without the need to connect to a PC.

Click model number for additional information.

AFG31021 25MHz, 1-Ch.
AFG31051 50MHz, 1-Ch.
AFG31101 100MHz, 1-Ch.
AFG31151 150MHz, 1-Ch.
AFG31251 250MHz, 1-Ch.
AFG31022 25MHz, 2-Ch.
AFG31052 100MHz, 2-Ch.
AFG31102 100MHz, 2-Ch.
AFG31152 150MHz, 2-Ch.
AFG31252 250MHz, 2-Ch.

Download Flyer





AFG31000 Series Intro Video
