Tektronix TBS1000C Digital Storage Oscilloscopes

The TBS1000C Series Digital Storage Oscilloscopes offer affordable performance in a smart, compact design. This versatile scope series is designed to meet the needs of today's educational institutions, embedded design engineers, and maker community with an improved user interface, innovative courseware system, and 5-year warranty.

  • 200 MHz, 100MHz, 70 MHz, and 50 MHz bandwidth models
  • 2-channel models
  • 7-inch WVGA color display with 15 horizontal divisions displaying 50% more signal
  • 1 GS/s sample rate on all channels
  • 20k point record length on all channels
  • Advanced triggers: pulse, runt, and line triggers
  • Pan and zoom capability
Models TBS1052C TBS1072C TBS1102C TBS1202C
Analog Channels 2 2 2 2
Bandwidth 50 MHz 70 MHz 100 MHz 200 MHz
Sample rate 1 GS/s
Record length 20 K points
Vertical Resolution 8 Bit, 1mV/div to 10V/div
Probe Interface Passive BNC probes, Current and Power probes
Trigger Edge, Pulse Width, Runt
Analysis 32 Automated Measurements, Cursors, FFT, Autoset, Math, Ref, Zoom
Display Size 7 in WVGA
I/O USB Host, USB Device, Aux In
Security Kensington Lock
Software Courseware, TekSmartLab, OpenChoice, TekBench
Warranty 5 Years

Downloads:
TBS1000C Series Data Sheet
