Elite RF AB002250M5650AC Linear RF Power Amplifier w/2U Rack, 2 to 250MHz, 400W, AB Series

Linear RF Power Amplifier

Elite RF’s AB002250M5650AC amplifier is a wideband power amplifier designed for CW signals fabricated on LDMOS process and can operate up to 250MHz. This amplifier offers high power density, low thermal resistance, and wideband performance. It can be widely used for military and commercial applications.

Specifications

• Frequency Range: 2 MHz to 250 MHz

• Output Power CW: 400 Psat Watts

• Gain (dbm): 50

• Mode: CW (Continuous Wave)

• AC Operating Voltage: 100-240 VAC, 120 VAC (typ)

• Size: 19.0 x 15.0 x 3.5

AB Series

Elite RF’s 500MHz to 2500MHz RF Power Amplifiers are among our popular series, incorporating advanced, state-of-the-art RF GaN transistors. These class AB linear amplifiers have a power gain up to 48dB and operate in CW or pulsed mode. Covering the UHF band and L band, these solid-state RF amplifiers are well-suited for a variety of applications, including defense, commercial and military radar, communications, industrial, scientific, medical, and laboratory use.

Series Features

• Wide Freq. Range

• High Output Power

• High Gain

• High Reverse Isolation

• Built-in Protection

• Protections

• Thermal Overload

• Over Voltage

• High VSWR

What's in the Box

• AB002250M5650AC Amplifier

• AC Power Cord

• Certificate of Conformance

• 2 Year Warranty

• Calibration not required
