Elite RF AA.01030G3025AC RF Power Amplifier w/2U Rack, 10 MHz to 30 GHz, 1 W Class A, AA Series

Broadband RF Power Amplifier

Elite RF’s AA.01030G3025AC amplifier is a wideband power amplifier designed for CW/pulsed signals fabricated on GaN on SiC process and can operate up to 30 GHz. This amplifier offers high power density, thermal resistance, low and wideband performance. It can be widely used for military and commercial applications.

Specifications

• Frequency Range: 10 MHz to 30 GHz

• Output Power CW: 1 Psat Watts

• Gain (dbm): 25

• Mode: CW (Continuous Wave)

• AC Operating Voltage: 100-240 VAC, 120 VAC (typ)

• Size: 19.0 x 15.0 x 3.5

AA Series

Elite RF’s solid-state broadband low power RF amplifiers offer wide spectrum coverage up to 30GHz. These Class A ultra linear RF amplifiers incorporate advanced GaN transistors and are designed for CW/pulsed signals. They offer high power density, low thermal resistance, and wideband performance, making them suitable for both military and commercial applications.

Series Features

• Wide Freq. Range

• High Output Power

• High Gain

• High Reverse Isolation

• Protections

• Thermal Overload

• Over Voltage

What's in the Box

• AA.01030G3025AC Amplifier

• AC Power Cord

• Certificate of Conformance

• 2 Year Warranty

• Calibration not required
