Keysight Infiniium EXR: Now with up to 6 GHz

If you want your designs to be first to market, you need to identify anomalies in high-speed signals faster and complete your compliance testing quickly. That’s why Keysight’s newest Infiniium EXR-Series oscilloscopes—offer up to 6 GHz of bandwidth and support for automated compliance testing.

	EXR-Series Specifications	Model	Channels	Max Sample Rate
Analog Channels	4 or 8, Upgradeable	EXR054A	4	16 GSa/s	Infiniium EXR-Series Data Sheet
Bandwidth	500 MHz to 6 GHz, Upgradeable	EXR104A	4	16 GSa/s	Infiniium EXR-Series Serial Bus Config Sheet
Sample Rate	16 GSa/s	EXR204A	4	16 GSa/s	Infiniium EXR-Series Power Integrity Config Sheet
Memory	100 Mpts, Upgradeable to 400 Mpts or 1.6 Gpts flexible memory	EXR254A	4	16 GSa/s	EXR-Series SMPS Testing Config. Guide
Resolution	10 bits, up to 16 with high resolution	EXR058A	8	16 GSa/s	EXR-Series SMPS Testing Application Note
ENOB	As high as 9.0	EXR108A	8	16 GSa/s
Digital Logic Channels	16, dedicated input, Upgradeable	EXR208A	8	16 GSa/s
Update Rate	> 200,000 wfm/s	EXR258A	8	16 GSa/s
Eye Diagram Speed	> 750,000 UI/s	EXR408A	8	16 GSa/s
Screen Display	15.6 touch, full HD, dual screen support	EXR258A	8	16 GSa/s

Who needs 6Hz?
Across industries, tomorrow’s innovations are already demanding increased speeds and higher frequencies.

Consumer Wireless

• MIPI protocols require a minimum bandwith of 4 GHz, and often 6 GHz

Automotive

• Automotive Ethernet 1000BASE-T1 requires at least 6 GHz of bandwith

Power Electronics and Motor Analysis

• High-Speed SiC and GaN device signals switch at high frequenices

High-Speed Digital Design

• High-Speed communication interfaces that are not standard protocols, like SerDes, have high throughputs

Meet the New Infiniium EXR Lineup

Keysight’s Infiniium EXR-Series includes eight models ranging in performance from 500 MHz to 6 GHz, 4 or 8 analog channels, with a 16 GSa/s sample rate available on all channels simultaneously. Add 100 Mpts of standard memory per channel, flexible three-stage triggering, over 50 standard measurements, a massive library of application-specific packages, and ASIC-accelerated testing, and you’ll see more of your signal than ever before.

Seven Instruments. One Scope.

Keysight’s EXR-Series InfiniiVision oscilloscopes integrate seven instruments in one convenient package that saves budget and bench space.

• Up to 8 high-speed analog oscilloscope channels
• 16 digital channels (logic analyzer)
• 50 MHz arbitrary waveform generator
• 50 MHz frequency response analyzer
• 10-digit counter
• 4-digit voltmeter
• Protocol analyzer
