Loctite 215848 Diaphragm Valve, 97136, 3mm Orifice

• Cost-effective valves for use with pressure-time systems
• Modular design and floating diaphragm allow for easy cleaning or repair
• Fail-safe spring assists closing of valve upon loss of air pressure
• Internal components are PTFE to prevent premature curing
• Flow rates can be increased with use of 3/8 in feed line
• Included in the box: (1) Diaphragm Valve, (1) product feed line 6.5 mm (0.25"), (1) needle variety kit, (1) operating manual.

LOCTITE Diaphragm Valves are pneumatically activated dispense valves that utilize a floating PTFE diaphragm. The valves can be mounted or handheld in conjunction with pressure-time dispense systems. The valves are not suited for cyanoacrylate products. The 3 mm (0.12 oz) orifice diaphragm valve is used with low- to medium-viscosity anaerobic and thixotropic products (2,500 to 5,000 mPa·s).
