UEi HVACKIT Hvac Clamp Meter Kit

Kit Features

EPC Clamp Meter

• Temperature & Capacitance
• TRMS
• 750/1000V AC/DC, 600A AC/DC
• AC/DC Microamps
• Dual Display
• Low Z (impedance)

INF165C 12:1 Infrared Thermometer

• Temperature -76 to 1022 F (-20 to 550 C)
• 12:1 distance-to-spot ratio

ATTPC4 Pipe Clamp Adapter

• Temperature range: -40 to 500 F (-40 to 260 C)
• Fits 3/16 inch to 1 7/16 inch pipes

AC550 Tool Backback

• Rigid waterproof base
• 2 zippered compartments with tool pockets
• Includes D-clip

The UEi HVACKIT bundles the most frequently used HVAC test instruments into a protective, foam‑lined carrying case, keeping each tool secure and easy to access. The kit includes the EPC Everyday Professional Clamp Meter, the INF165C infrared thermometer, the ATTPC4 compact K‑Type pipe clamp, and the AC550 tool backpack.

The EPC clamp meter is safety rated for 400A at CAT IV 600V and CAT III 1000V. It provides measurements for AC/DC voltage, LRA inrush current, temperature, capacitance, duty cycle, AC amperage, DC microamps, frequency through test leads, non‑contact voltage, resistance, continuity, and diode checks.

The ATTPC4 is a wired K‑Type pipe clamp featuring a thermally isolated sensor that shields readings from ambient temperature effects. Its rugged, compact build makes it easy to secure onto pipes even in tight or crowded spaces.

The INF165C infrared thermometer uses a distinctive circular laser targeting pattern and offers a 12:1 distance‑to‑spot ratio. It covers the key HVAC temperature range and supports remote measurements with adjustable emissivity and max‑value capture. The HVACKIT comes with a 1‑year limited warranty.

What's in the Box

• Meter: EPC
• Test Leads: ATL70
• Alligator Clips: Yes
• Batteries: AAA (6)
• Pouch/Case: AC550
• Pipe Clamp Probe: ATTPC4
• Infrared Thermometer: INF165C
