• Equipped with Bluetooth™ Communication enabled via the Greenlee Gator Eye app
• Features LED display screen communicating pressure and battery levels as well as tool diagnostics with real-time tool feedback
• Intelligent Crimping System Technology includes a pressure sensor that monitors the crimping force of each crimp and provides the operator a visual and audible alert if the force is below specifications
• State of the art 18V lithium ion (Li-ion) battery provides 70% more cycles per charge and faster cycle times
• Automatic Retraction Stop (ARS) which retracts the ram just enough to get ready for the next cycle saving time and energy
• LED light provides the operator with the battery charge and tool maintenance status
• Two-stage hydraulic system provides fast advance and power speeds, saving time
• Forward handle position improves tool balance
• One trigger controls all tool functions
• Crimping head rotates 350°
• Tools automatically retract when the crimping cycle is complete
• Overmolded tacky grip areas make gripping the tool easier and more comfortable
• LED work light illuminates dark work areas
• Greenlee battery-powered crimping tools now use bio-degradable oil
• Smart chargers control the charging current, charging voltage and battery temperature to maximize battery life
• Flip open crimping head will allow crimping of 4 AWG-1000 kcmil copper or 6 AWG-1000 kcmil aluminum with no dies to change
• Available with 120V, 12V or 230V battery charger or with 120V or 230V corded adapter in place of batteries and charger

Equipped with Bluetooth™ Communication enabled via the Greenlee Gator Eye app. Features LED display screen communicating pressure and battery levels as well as tool diagnostics with real-time tool feedback


Product Details:

• Sub Brand : Gator
• Type : Dieless style crimper
• Application : 12 Ton Crimping
• Standard : C/US UL Listed
• Wire Size : 4 AWG - 1000 kcmil Cu
• Wire Size : 6 AWG - 1000 kcmil Al
• Overall Length : 16.5 IN (420mm)
• Crimping Force : 24,000 lbs. (106 kN)
• Crimping Capacity : 1000 Kcmil (MCM) Cu & Al
• Connector Type : Color-coded lugs and splices
• Handle Type : Pistol Style with over molded rubber grip
