Keysight L7106B 024 100 Multiport Coaxial Switch DC to 20 GHz SP6T 24VDC Solder Termination L-Series

17004.2 MFG #: L7106B 024 100
$1,393.00 / EA
  • Condition: New
  • Drill Down Description: Multiport Coaxial Switch, DC to 20 GHz, SP6T, 24VDC, Solder Termination, L-Series
  • Model: L7106B 024 100
  • Quote Required: No
  • Web Meta Description: Buy Keysight L7222C 161 201 Multiport Coaxial Switch from TestEquity.
  • Series: L Series

QTY
  • Description

    The Keysight L7106B multiport switch improves accuracy in signal RF and microwave signal routing and testing applications. This economically-priced, electro-mechanical switch provides unmatched isolation and a 0.03 dB insertion loss repeatability, which is warranted for the 2-million life cycle of the switch. The L7106B’s low insertion loss repeatability reduces sources of random errors in the measurement path, which improves measurement accuracy. The repeatability and reliability of this switch guarantee measurement accuracy and can cut the cost of ownership by reducing calibration cycles and increasing test system up time. Highly repeatable switching capability is made possible through Keysight's rigorous design and tight manufacturing specifications.

    Ideal for manufacturing test engineers working on system integration, the Keysight L7106B terminated multiport switch provides an economically-priced, reliable solution for signal monitoring, and routing applications.

    Key Features & Specifications
    • SP6T configuration, terminated
    • Electronic position indicator
    • Current interrupt capability
    • Magnetic latching
    • Superior RF Performance
    • Unmatched isolation, typically 90 dB at 12 GHz
    • Operating life of 5 million cycles, typical
    • Guaranteed repeatability of 0.03 dB up to 2 million cycles
