• Includes pH electrode CPC-OSH-12-01 (for food)
• pH measuring range: 0-14 pH
• Supplied with calibration solution pH4 + 7 (75 ml vials each)
• Waterproof IP67
• Auto-power-off for battery conservation
• Data hold function
• Easy-to-read digital display
• Resolution: 0.01 pH

The PCE-PH20M Environmental meter was developed to directly determine the pH of food and meat. The waterproof pH tester is used for the fast and accurate measurement of pH. The practical display makes the pH value on the pH meter easy to read. Due to the waterproof and robust housing (IP 67), the pH value tester can also be used under difficult conditions. A recalibration always guarantees optimum accuracy and is very easy to perform using the optionally available calibration kits (automatic calibration function without calibration screws - to be performed only via the keyboard).

pH of meat products
The pH measurement in the production and processing of foodstuffs is a ubiquitous method of measurement. It is needed in many downstream process steps and has a direct influence on the tactile, sensory, and hygienic quality of future foodstuffs.

Practical example: pH-control in the production of aspic and aspic sausage
In the production of aspic, besides the artisanal production of animal constituents (paws and rinds), there is also the use of industrially produced gelatin. It consists largely of similar animal ingredients but is produced industrially.

The so-called bloom number characterizes gelatin and defines the subsequent firmness of the aspic. This means: the higher the bloom number is, the higher the firmness. The reference values are the following: bloom numbers < 160 are defined as lower, the bloom numbers > 220 are defined as higher.

However, the other factors also play an equally important role in the firmness of the subsequent aspic.

• Amount of the added gelatin
• Bloom number
• Temperature of the finished jelly, as well as the heating and cooling process during the manufacturing
• the pH value

In the production of aspic, an edible gelatin is first swelled in cold water and then heated carefully at 50-60 ° C with stirring. During this process the gelatin dissolves. In case of aspic powder the swelling can be omitted and the water can be heated more (up to 80 °C). Spices and depending on the product different amounts of vinegar are added to this gelatin mass. In this case, the added amount of the vinegar influences the pH value of the gelatin mass.

Because of the hygienic reasons, an acidic pH value is always an advantage; depending on the type of aspic and also for the reasons of taste. However, the pH has a direct influence on the firmness of aspic. So the aspics with the pH range of pH 3-4 have got a 10-20% lower firmness than the aspics with the pH 5. In order to reach the desired aspic firmness in each product, depending on the used vinegar amount gelatin with an appropriate bloom number must be used. Also, the vinegar can be added to the aspic shortly before the end, in addition to the gelatin. In these cases, the gelatins with lower bloom number can be used then. Depending on the subsequent aspic the optimum "process conditions" regarding the type of gelatin, temperature (exposure time) can be found. The pH defines the characteristics and must be measured in the working process.

What's in the Box

• 1x Environmental meter PCE-PH20M
• 1x pH electrode CPC-OSH-12-01 (for food)
• 4x 1.5V AAA batteries
• 1x Calibration kit with solutions pH4 + 7 (each 75 ml vial)
• 1x Instruction manual
