NOTE: Photo may not be representative of the connector type for this configuration.

• N4432D/003/010: Four 3.5 mm female connectors on module, 300 kHz to 26.5 GHz
• Precision 4-ports RF ECal module with high accuracy
• Fast, easy, and accurate full 4-ports calibration
• Direct control from Keysight vector network analyzers via USB

Keysight N4432D RF electronic calibration (ECal) module makes calibration of Keysight vector network analyzers fast, easy and accurate.

This ECal module is an ideal solution for calibrating vector network analyzers. Performing a full 4-ports calibration takes less than half the time and number of connections versus traditional mechanical cal kits. The operator simply connects the ECal module to the vector network analyzer via USB and the firmware controls the rest, thus reducing the chance for operator error. Wear and tear on connectors are reduced as well, lowering repair costs on both the test port connectors and calibration standards.

N4433D is a precision 4-ports ECal module that supports selection of connectors of 3.5 mm connectors and can be mixed up to 26.5 GHz. Select either female-female, male-male, or female-male connectors.

Connector Options:
Note: If option 010 is not chosen, then you must choose the connector type for each of the four ports.
