DISCONTINUED

• 4 Analog channels, 1 GHz
• 16 Digital channels
• Up to 60.6 ps timing resolution with MagniVu™
• 1 Spectrum Analyzer (RF) channel, 9 kHz to 6 GHz
• Ultra-wide capture bandwidth ≥1 GHz
• Normal, Average, Max Hold and Min Hold Traces
• +Peak, -Peak, Average and Sample Detection
• Spectrogram display
• Sample rates: 5 GS/s
• Standard passive voltage probes with 3.9 pF capacitive loading and 1 GHz analog bandwidth
• 20M points standard record length on all channels
• Over 135 available trigger combinations
• Wave Inspector® to automatically search and easily navigate waveforms
• 44 Automated measurements and FFT analysis
• Front panel USB host ports for data storage
• Serial bus triggering and analysis options
• Parallel bus triggering and analysis, including multi-channel set-up and hold triggering (included standard)
