SMCV100BP2 Vector Signal Generator Package

Includes:

• SMCVB-B103 8kHz to 3GHz
• SMCVB-K197 AM/FM/Phase Modulation (Via Baseband)
• SMCVB-K198 Pulse Modulation (Via BB)
• SMCVB-K199 Custom Digital Modulation

Key Features of the SMCV100B:

• Multi-standard platform for broadcast, navigation, cellular and wireless applications
• Full software option defined vector signal generator with 5" touchscreen
• Modern RF signal generation concept from 8kHz to 3GHz
• High output power to +16 dBm
• Playback of long I/Q sequences from solid state disk drive for EMC testing
• Internal baseband signal generation with ARB
• SCPI macro recorder

Benefits:
The R&S SMCV100B features a new direct RF DAC concept for RF signal generation. This concept enables I/Q modulation and upconversion in the digital domain, eliminating the I and Q imbalance errors and LO leakage found in conventional analog I/Q modulators.

The R&S SMCV100B options concept is fully software defined. No additional hardware needs to be installed to maintain full device functionality. This also includes the upgrade of the RF frequency, memory, I/Q modulation bandwidth and all other R&S SMCV100B options that can be used to cover different applications.

Highest flexibility in applications and production:
The R&S SMCV100B vector signal generator is the first multistandard platform for automotive, broadcast, navigation and wireless applications. This makes the R&S SMCV100B unique for use in many applications, from the lab to production and wherever different technologies meet.

Highlights:

• Modern and flexible
• Perfect match for a wide range of signals
• Latest transmission standards for testing 5G NR and NB-IoT devices
• Fully software defined vector signal generator
• Perfect fit in the lab and in production
• Expandable for future requirements
• Modern RF signal generation with direct digital RF upconversion concept
• Wide range of applications
