Rohde & Schwarz Three-Path Diode Power Sensors

Ideal for universal applications

Three-path diode power sensors are suitable for numerous applications since they support continuous average, burst average, timeslot average, gate average and trace measurements. The NRPXXS/SN three-path diode power sensors can be operated with the NRX base unit, with a laptop/ PC via USA or LAN, and with many Rohde & Schwarz instruments. Featuring outstanding performance and unprecedented measurement speed and accuracy, the sensors can be used to perform precise average power measurements on wireless signals ranging from GSM and LTE up to 5G NR. For detailed analysis, the sensors offer additional measurement functions such as timeslot mode and trace mode with a video bandwidth of 100 kHz.

Request a Quote




Sensor Type Frequency Range Level Range Connector Type
NRP8S.02 10 MHz to 8 GHz -70 dBm to +23 dBm N (m)
NRP18S.02 10 MHz to 18 GHz -70 dBm to +23 dBm N (m)
NRP33S.02 10 MHz to 33 GHz -70 dBm to +23 dBm 3.5 mm (m)
NRP40S.02 50 MHz to 40 GHz -70 dBm to +20 dBm 2.92 mm (m)
NRP50S.02 50 MHz to 40 GHz -70 dBm to +20 dBm 2.4 mm (m)
NRP8SN.02 10 MHz to 8 GHz -70 dBm to +23 dBm N (m)
NRP18SN.02 10 MHz to 18 GHz -70 dBm to +23 dBm N (m)
NRP33SN.02 10 MHz to 33 GHz -70 dBm to +23 dBm 3.5 mm (m)
NRP40SN.02 50 MHz to 40 GHz -70 dBm to +20 dBm 2.92 mm (m)
NRP50SN.02 50 MHz to 50 GHz -70 dBm to +20 dBm 2.4 mm (m)
