Keysight EL30000 Series Bench Electronic Loads

The new Keysight EL30000 Series bench electronic load lets you measure, capture and quickly display static and dynamic events. Single- and dual-channel models with up to 600W provide superior performance in a compact form factor – ideal to verify designs ranging from consumer power supplies, batteries and battery modules to solar panels, LED drivers, and power converters.

The EL30000 is fully SCPI programmable with built-in USB, LAN and Optional BPIB interfaces.

  • Test voltages up to 150V
  • Sink current up to 60 or 120A
  • Use operating Modes: constant voltage (CV), constant current (CC), constant resistance (CR), constant power (CP)
  • Display measurements, data logging, or scope view

• Save data internally or to an external USB flash drive
• Improve load regulation with 4-wire remote sense
• Create dynamic load profiles with device's LIST function

• Connect with USB, LAN (LXI Core), and optional GPIB


With the new EL30000 Series electronic loads, you can characterize most devices without additional equipment. Need higher current and more power? Combine the two inputs into a single channel — measure up to 120 A or 600 W.



EL34143A
Channel 1
Input power 350 W
DC input voltage 150 V
DC input Current 60 A



EL34243A
Channel 1 2
Input power 300 W 300 W
DC input voltage 150 V 150 V
DC input Current 60 A 60 A
DC input current (parallel) 120 A
