UNI-T

UNI-T MSO8000HD-PCIe2 PCIe Bus Trigger and Analysis Option, For MSO8000HD Series

Our Part #20020934

Mfr Part #MSO8000HD-PCIe2

UNI-T MSO8000HD-PCIe2
UNI-T

UNI-T MSO8000HD-PCIe2 PCIe Bus Trigger and Analysis Option, For MSO8000HD Series

Our Part #20020934

Condition:New

Mfr Part #MSO8000HD-PCIe2

WARNING
RoHS
$2,999.00EACH
Digital Product
Manufacturer Lead Time :20 Days

Condition:New

Calif. Prop 65
RoHS

Uni-T MSO8000HD-PCIe2 PCIe Bus Trigger and Analysis Option

Key Features

  • Complete PCIe 1.0 and 2.0 protocol decoding and analysis
  • Transaction Layer Packet (TLP) analysis with header and payload decoding
  • Data Link Layer Packet (DLLP) and Physical Layer analysis
  • Link training and status state machine (LTSSM) monitoring
  • Advanced triggering on PCIe-specific events and transaction types
  • Credit-based flow control analysis and monitoring
  • Error detection and recovery mechanism validation
  • Lane deskew and symbol alignment analysis for multi-lane links
  • Integration with signal integrity analysis for physical layer characterization
  • Protocol search and navigation through extensive PCIe transaction captures
  • Automated protocol analysis reporting with detailed transaction statistics
  • Seamless integration with MSO8000HD's advanced measurement ecosystem

The UNI-T MSO8000HD-PCIe2 option provides comprehensive PCI Express protocol analysis capabilities for PCIe 1.0 and 2.0 interfaces, enabling engineers to decode, trigger on, and analyze PCIe communications with complete transaction-level visibility. This professional analysis tool delivers detailed insight into PCIe packet structure, link training sequences, and protocol performance, essential for validating PCIe-based communication systems and troubleshooting high-speed interconnect issues.

Designed for engineers working with computer systems, embedded computing, industrial automation, and high-speed data acquisition applications, the PCIe2 option combines advanced protocol decoding with the MSO8000HD's exceptional signal integrity analysis capabilities. This integration enables simultaneous analysis of PCIe transaction content and physical layer characteristics, providing complete visibility into both protocol compliance and signal quality for robust PCIe system validation.


BrandUNI-T
Alternate Product Number191503200003
