- The protocol frame can be configured, including preamble, frame ID, data, CRC and more
- Display of all decoded telegrams as color-coded bus signals or in tabular form, as defined in the frame configuration
- Triggering on start of frame, frame ID and data. Maximum data rate for triggering of 50 Mbit/s
- Support of up to 50 different frame formats
- Fastest eye-diagram mask testing with standard mask test functionality
Oscilloscope software
The R&S®RTO and R&S®RTE oscilloscopes support triggering and decoding of any Manchester and NRZ coded serial protocol with data rates up to 5 Gbit/s, including Manchester violation detection. You can define up to 50 different frame formats. Errors are identified reliably and efficently using the hardware-accelerated trigger. You can trigger on start of frame, frame ID and data.
Brand:Â Rohde & Schwarz
Type:Â Trigger and Decode Bundle
Series:Â RTO Series
Alternate Product Number:Â 1329.7531.02
Series Compatibility:Â RTO Series
