Pomona 5790-2 Rotating Micrograbber Test Clip w/Two .025" Sq. Pins, 2 A, 70 V, Red, 5790 Series
Our Part #34037.1
Mfr Part #5790-2
Pomona
Pomona 5790-2 Rotating Micrograbber Test Clip w/Two .025" Sq. Pins, 2 A, 70 V, Red, 5790 Series
Our Part #34037.1
Condition:New
Mfr Part #5790-2
$EACH
- Description
- Specifications
- Documents
- Mates with Model #’s 4771, 4772 or 4741 square pin receptacles.
- The rotating Micrograbber Test Clip is ideal for testing surface mounted devices (SMDs), high density leads with 1.2 (0.05) spacing, and fine gauge wires 0.1 (0.004).
- Two access entries with 0.6 (.025) square pins.
- Rotating pincers grasp leads firmly.
- Extended guide tube reaches into right areas and can be bent to a 35° angle.
Brand:Â Pomona
Series:Â 5790 Series
Current:Â 2 A
Insulation:Â Nylon
Maximum Temperature: 176°F
Voltage Rating:Â 70 V
Wire Material:Â Steel
