Keysight InfiniiVision 3000T X-Series Oscilloscopes
Expect more from your general-purpose oscilloscope.
The 3000 T-Series provides the performance and capability you need to get to measurement insights faster with a capacitive touch screen, user interface designed for touch, zone touch trigger, and industryleading waveform update rates. Have confidence that you see your complete signal detail to discover any issues quickly.
InfiniiVision 3000 X-Series Oscilloscopes
- 100 MHz - 1 GHz, DSO and MSO models
- Speed testing with simplified operation and documentation enabled by the 8.5-inch capacitive touch screen
- Isolate signals in seconds with exclusive Zone Touch Triggering
- See the most signal detail with 1,000,000 wfms/s update rate
- Quickly modulate and characterize signals with built-in WaveGen 20 MHz ARB, 3-digit voltmeter and 8-digit frequency counter & totalizer options
- Decode serial busses faster with hardware-based serial analysis options
- Protect your investment with full upgrade-ability
Making your measurements is as easy as touch, discover, solve
Make faster measurements with exclusive Zone Touch Triggering
• Advanced triggering becomes as simple as drawing a box (zone)
• If you can see an anomaly on screen, you can trigger on it
• Simply draw a box around the area to isolate, and choose ‘must intersect’ or ‘must not intersect’ and the scope does the work for you
Easily solve your measurement challenges with 6-in-1 instrument integration
• Logic analyzer (MSO) option adds 16 digital channels
• Serial protocol analyzer options add triggering and analysis capabilities for the widest range of serial buses
• WaveGen function/arbitrary waveform generator option adds waveform generation capabilities within the scope
| Model | Description | Bandwidth | Channels | Max Memory | Max Sample Rate | Waveform Update Rate |
| DSOX3012T | Digital Storage Oscilloscope | 100 MHz | 2 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3012T | Mixed Signal Oscilloscope | 100 MHz | 2 + 16 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| DSOX3014T | Digital Storage Oscilloscope | 100 MHz | 4 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3014T | Mixed Signal Oscilloscope | 100 MHz | 4 + 16 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| DSOX3022T | Digital Storage Oscilloscope | 200 MHz | 2 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3022T | Mixed Signal Oscilloscope | 200 MHz | 2 + 16 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| DSOX3024T | Digital Storage Oscilloscope | 200 MHz | 4 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3024T | Mixed Signal Oscilloscope | 200 MHz | 4 + 16 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| DSOX3032T | Digital Storage Oscilloscope | 350 MHz | 2 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3032T | Mixed Signal Oscilloscope | 350 MHz | 2 + 16 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| DSOX3034T | Digital Storage Oscilloscope | 350 MHz | 4 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3034T | Mixed Signal Oscilloscope | 350 MHz | 4 + 16 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| DSOX3052T | Digital Storage Oscilloscope | 500 MHz | 2 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3052T | Mixed Signal Oscilloscope | 500 MHz | 2 + 16 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| DSOX3054T | Digital Storage Oscilloscope | 500 MHz | 4 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3054T | Mixed Signal Oscilloscope | 500 MHz | 4 + 16 | 1 Mpts | 5 GSa/s | N/A |
| DSOX3102T | Digital Storage Oscilloscope | 1 GHz | 2 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3102T | Mixed Signal Oscilloscope | 1 GHz | 2 + 16 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| DSOX3104T | Digital Storage Oscilloscope | 1 GHz | 4 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
| MSOX3104T | Mixed Signal Oscilloscope | 1 GHz | 4 + 16 | 1 Mpts | 5 GSa/s | 1,000,000 wfms/s |
