6 Series B MSO: More Bandwith. More Channels. Less Noise.
Tektronix 6 Series B Mixed-Signal Oscilloscope
Embedded designs are getting smarter. Incorporating more sensors. Using faster clocks and high-speed serial buses to move and process more data. Introducing the industry’s first 10 GHz mixed-signal oscilloscope with 4, 6 or 8 channels, designed to meet the needs of today’s most demanding applications.
The Tektronix 6 Series B mixed-signal oscilloscope combines the same great usability of previous models with significant advancements. Beautifully designed, this high-precision instrument features more bandwidth, channels and speed with less noise. You’ll also benefit from the largest (15.6” HD) capacitive pinch-zoom-swipe touch display on the market with intuitive drag and drop, object-oriented user interface.
All the features and capabilities required for advanced automotive, aerospace, defense, and semi-conductor applications:
- More Channels: 4, 6 or 8 Flexchannel inputs
- Leading signal fidelity with 12-bit ADCs and extremely low noise
- 12-bit ADCs and low-noise preamps for accurate measrements
- Powerful built-in measurements, statistics and trend plots
- TekVPI probe interfaces support a wide range of probes
- Application-specific measrements and automated testing
Addresses the new requirements of high-speed data movement and processing in embedded designs. Learn more about the new Tektronix 6 Series MSO.
| Model | Bandwidth | Channels | Vert. Resolution | Record Length |
| MSO64B 6-BW-1000 | 1 GHz | 4 | 12-bits | 62.5 M |
| MSO64B 6-BW-2500 | 2.5 GHz | 4 | 12-bits | 62.5 M |
| MSO64B 6-BW-4000 | 4 GHz | 4 | 12-bits | 62.5 M |
| MSO64B 6-BW-6000 | 6 GHz | 4 | 12-bits | 62.5 M |
| MSO64B 6-BW-8000 | 8 GHz | 4 | 12-bits | 62.5 M |
| MSO64B 6-BW-10000 | 10 GHz | 4 | 12-bits | 62.5 M |
| MSO66B 6-BW-1000 | 1 GHz | 6 | 12-bits | 62.5 M |
| MSO66B 6-BW-2500 | 2.5 GHz | 6 | 12-bits | 62.5 M |
| MSO66B 6-BW-4000 | 4 GHz | 6 | 12-bits | 62.5 M |
| MSO66B 6-BW-6000 | 6 GHz | 6 | 12-bits | 62.5 M |
| MSO66B 6-BW-8000 | 8 GHz | 6 | 12-bits | 62.5 M |
| MSO66B 6-BW-10000 | 10 GHz | 6 | 12-bits | 62.5 M |
| MSO68B 6-BW-1000 | 1 GHz | 8 | 12-bits | 62.5 M |
| MSO68B 6-BW-2500 | 2.5 GHz | 8 | 12-bits | 62.5 M |
| MSO68B 6-BW-4000 | 4 GHz | 8 | 12-bits | 62.5 M |
| MSO68B 6-BW-6000 | 6 GHz | 8 | 12-bits | 62.5 M |
| MSO68B 6-BW-8000 | 8 GHz | 8 | 12-bits | 62.5 M |
| MSO68B 6-BW-10000 | 10 GHz | 8 | 12-bits | 62.5 M |
